Description

Shop Legrand Mosaic Equipotential Socket 1 Module White Antimicrobial | 078700 In Iraq Best Prices

Legrand Mosaic equipotential socket with antimicrobial treatment for hospital environments. Conforms to DIN 42801 and IEC 60364-7-710 standards. 1-module flush-mounted design with silver compound antibacterial protection.
The Legrand Mosaic Equipotential Socket is a specialized electrical outlet designed for use in hospital environments and sensitive medical facilities. This 1-module white antimicrobial socket equalizes the voltages of all conductive elements and exposed conductive parts, effectively limiting contact voltage to safe levels for personnel. The equipotential socket conforms to international standards DIN 42801 and IEC 60364-7-710, making it an essential component for healthcare infrastructure where prevention of equipment disturbance is critical. Featuring antimicrobial treatment with silver compound technology, this socket prevents bacterial growth on its surface, ensuring hygienic operation in sterile environments. The flush-mounted design integrates seamlessly into existing wall installations with a sleek white finish. With an IP41 protection rating and IK04 impact resistance, this socket provides reliable performance in demanding hospital settings. The thermoplastic construction is halogen-free, meeting modern environmental and safety standards for medical facilities. The Mosaic range represents the pinnacle of electrical socket technology for healthcare applications. Each unit is individually tested and certified to ensure compliance with strict medical facility requirements. Installation is straightforward with basic element mounting using a central cover plate system. The compact dimensions (22.5mm width, 45mm height, 40mm depth) allow for flexible placement in various wall configurations without compromising aesthetic appeal or functionality.

Key Features

  • Equipotential socket equalizes voltages of all conductive elements for safe medical environments
  • Antimicrobial silver compound treatment prevents bacterial growth on surface
  • Complies with international standards DIN 42801 and IEC 60364-7-710
  • Flush-mounted 1-module design with central cover plate for seamless wall integration
  • IP41 protection rating and IK04 impact resistance for hospital durability
  • Halogen-free thermoplastic construction meets modern environmental standards
  • Glossy white finish maintains aesthetic appeal in healthcare facilities
  • Operating temperature range -5°C to 35°C ensures reliable performance

Technical Specifications

Specification Value
BrandLegrand
Product LineMosaic
Reference Number078700
EAN Code3245060787004
Product TypeEquipotential Socket Outlet
Module Configuration1 Module
ColorWhite Antimicrobial
RAL Number (Similar)9003
MaterialThermoplastic
Halogen FreeYes
Antimicrobial TreatmentYes - Silver Compound
Surface FinishingGlossy
Mounting MethodFlush-mounted
Assembly ArrangementBasic Element with Central Cover Plate
Width22.5 mm
Height45 mm
Depth40 mm
Built-in Depth16 mm
Degree of Protection (IP)IP41
Impact Strength (IK)IK04
Operating Temperature Range-5°C to 35°C
Storage Temperature Range-10°C to 70°C
International StandardsDIN 42801, IEC 60364-7-710
ApplicationHospital Environments - Medical Facility Use
FunctionVoltage Equalization and Contact Voltage Limitation

Order Legrand Mosaic Equipotential Socket 1 Module White Antimicrobial | 078700 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.

Product form

Legrand Mosaic Equipotential Socket 1 Module White Antimicrobial | 078700

    SKU: 078700

      Description

      Shop Legrand Mosaic Equipotential Socket 1 Module White Antimicrobial | 078700 In Iraq Best Prices

      Legrand Mosaic equipotential socket with antimicrobial treatment for hospital environments. Conforms to DIN 42801 and IEC 60364-7-710 standards. 1-module flush-mounted design with silver compound antibacterial protection.
      The Legrand Mosaic Equipotential Socket is a specialized electrical outlet designed for use in hospital environments and sensitive medical facilities. This 1-module white antimicrobial socket equalizes the voltages of all conductive elements and exposed conductive parts, effectively limiting contact voltage to safe levels for personnel. The equipotential socket conforms to international standards DIN 42801 and IEC 60364-7-710, making it an essential component for healthcare infrastructure where prevention of equipment disturbance is critical. Featuring antimicrobial treatment with silver compound technology, this socket prevents bacterial growth on its surface, ensuring hygienic operation in sterile environments. The flush-mounted design integrates seamlessly into existing wall installations with a sleek white finish. With an IP41 protection rating and IK04 impact resistance, this socket provides reliable performance in demanding hospital settings. The thermoplastic construction is halogen-free, meeting modern environmental and safety standards for medical facilities. The Mosaic range represents the pinnacle of electrical socket technology for healthcare applications. Each unit is individually tested and certified to ensure compliance with strict medical facility requirements. Installation is straightforward with basic element mounting using a central cover plate system. The compact dimensions (22.5mm width, 45mm height, 40mm depth) allow for flexible placement in various wall configurations without compromising aesthetic appeal or functionality.

      Key Features

      • Equipotential socket equalizes voltages of all conductive elements for safe medical environments
      • Antimicrobial silver compound treatment prevents bacterial growth on surface
      • Complies with international standards DIN 42801 and IEC 60364-7-710
      • Flush-mounted 1-module design with central cover plate for seamless wall integration
      • IP41 protection rating and IK04 impact resistance for hospital durability
      • Halogen-free thermoplastic construction meets modern environmental standards
      • Glossy white finish maintains aesthetic appeal in healthcare facilities
      • Operating temperature range -5°C to 35°C ensures reliable performance

      Technical Specifications

      Specification Value
      BrandLegrand
      Product LineMosaic
      Reference Number078700
      EAN Code3245060787004
      Product TypeEquipotential Socket Outlet
      Module Configuration1 Module
      ColorWhite Antimicrobial
      RAL Number (Similar)9003
      MaterialThermoplastic
      Halogen FreeYes
      Antimicrobial TreatmentYes - Silver Compound
      Surface FinishingGlossy
      Mounting MethodFlush-mounted
      Assembly ArrangementBasic Element with Central Cover Plate
      Width22.5 mm
      Height45 mm
      Depth40 mm
      Built-in Depth16 mm
      Degree of Protection (IP)IP41
      Impact Strength (IK)IK04
      Operating Temperature Range-5°C to 35°C
      Storage Temperature Range-10°C to 70°C
      International StandardsDIN 42801, IEC 60364-7-710
      ApplicationHospital Environments - Medical Facility Use
      FunctionVoltage Equalization and Contact Voltage Limitation

      Order Legrand Mosaic Equipotential Socket 1 Module White Antimicrobial | 078700 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
