Premium dual USB Type-C charging socket with 5V/3A power delivery, surge protection over 1kV, Class II SELV safety, and efficient 15W output for fast charging smartphones and tablets.
The Legrand Mosaic Double USB Type-C + Type-C charging socket is a modern and efficient solution for powering and charging portable devices. This premium charging socket features dual USB Type-C ports, delivering 5V at 3A with a total power output of 15W, making it ideal for smartphones and fast-charging tablets and portable computers. Designed with the Mosaic programme mechanisms, this socket provides universal compatibility with all USB Type-C equipped devices while maintaining high efficiency standards.
This charging socket incorporates advanced surge protection with protection greater than 1kV, ensuring your valuable devices remain safe from electrical fluctuations. The socket operates on AC/DC power supply with the highest efficiency level (VI classification), consuming less than 0.07W in passive mode. It features Class II SELV (Safety Extra Low Voltage) protection and comes with 2x2.5mm² screw terminals for secure installation. The white finish (RAL 9003) complements any modern interior design, while the 2-module configuration fits standard flush-mounted receptacles for floor sockets.
With its halogen-free construction and compliance with international standards including IEC 62680-1-3, this Legrand Mosaic USB charging socket represents the perfect blend of functionality, safety, and contemporary design. The device operates reliably between 0-45°C and provides an impact resistance rating of IK04, making it suitable for various residential and commercial applications.
Key Features
- Dual USB Type-C ports for universal device compatibility and simultaneous charging
- 5V/3A power delivery with 15W total output for fast charging smartphones and tablets
- Advanced surge protection exceeding 1kV for device safety and longevity
- Class II SELV (Safety Extra Low Voltage) protection with halogen-free construction
- Ultra-low passive mode consumption at 0.07W with highest efficiency rating (VI)
- Flush-mounted installation with 2x2.5mm² screw terminals for secure connection
- Compliant with IEC 62680-1-3 international standards for USB Type-C charging
- Modern white finish (RAL 9003) with 2-module Mosaic programme design
- Operating temperature range 0-45°C with IK04 impact resistance rating
- IP40 degree of protection for indoor residential and commercial applications
Technical Specifications
| Specification |
Value |
| Product Reference | 077590 |
| EAN Code | 3414971003323 |
| Brand | Legrand |
| Product Line | Mosaic Programme |
| Socket Type | Double USB Type-C + Type-C Charging Socket |
| Number of Modules | 2 modules |
| USB Port Configuration | 2x USB Type-C ports |
| Output Voltage | 5V DC |
| Maximum Output Current | 3A (3000 mA) |
| Total Power Output | 15W |
| Input Voltage Range | 100-240V AC |
| Frequency | 50-60 Hz |
| Power Consumption (Passive Mode) | 0.064W (less than 0.07W) |
| Efficiency Rating | VI (Highest Level) |
| Connection Type | Screw Terminals |
| Terminal Capacity | 1.5-2.5 mm² |
| Number of Terminals | 2 |
| Cable Type | Flexible or Rigid |
| Mounting Method | Flush-mounted |
| Installation Depth | 33 mm built-in, 40 mm minimum box depth |
| Device Dimensions | 45mm (width) x 45mm (height) x 42mm (depth) |
| Color | White |
| RAL Number | 9003 |
| Safety Classification | Class II SELV (Safety Extra Low Voltage) |
| Surge Protection | Greater than 1kV |
| International Standard Compliance | IEC 62680-1-3 |
| Degree of Protection (IP) | IP40 |
| Impact Strength Rating (IK) | IK04 |
| Operating Temperature Range | 0-45°C |
| Storage Temperature Range | -20-70°C |
| Voltage Type | AC |
| Power Delivery Support | No |
| Antimicrobial Treatment | No |
| Wireless Capability | No |
| Halogen Free | Yes |
| Terminal Marking | Yes |
| Stress Test Conformity (1000V) | No |
| Neutral Connection | Mandatory |
| Supply Current | 0.5A |
