Shop Legrand Mosaic German Standard Socket Outlet 2P+E Antibacterial | 078702 In Iraq Best Prices
Premium antimicrobial German standard socket outlet with child protection shutters, 16A 250V, white finish, ideal for healthcare and high-touch environments
The Legrand Mosaic Antibacterial Socket Outlet is a premium German standard electrical outlet designed for modern residential and commercial installations. This 2-module device features advanced antimicrobial protection with a silver compound coating that prevents bacterial growth on the surface, making it ideal for healthcare facilities, kitchens, and high-touch environments. The outlet is rated for 16A at 250V and supports both 50-60Hz frequencies, ensuring compatibility with various electrical systems. With its white glossy finish and enhanced contact protection with shutters for child safety, this socket outlet combines functionality with safety and hygiene. The device features screw terminals for secure cable connections and can be installed in flush-mounting boxes, surface-mounting boxes, floor boxes, column modules, desktop multi-outlet extensions, office modules, and trunking systems. The antimicrobial treatment is permanent and does not wear off with normal use, providing long-lasting protection against bacterial contamination.
Key Features
- Antimicrobial silver compound coating prevents bacterial growth on surface
- Enhanced contact protection with safety shutters for child protection
- German standard 2P+E socket outlet with 16A 250V rating
- Compatible with 50-60Hz frequency for global electrical systems
- Versatile installation options including flush-mounting, surface-mounting, floor boxes, and trunking
- Screw terminal connections for secure cable attachment
- White glossy thermoplastic housing with halogen-free material
- IP41 degree of protection and IK04 impact strength rating
- Loop-through function for daisy-chain installation capability
- Compact 2-module design fitting standard installation boxes
Technical Specifications
| Specification |
Value |
| Product Reference | 078702 |
| EAN Code | 3245060787028 |
| Brand | Legrand |
| Product Line | Mosaic |
| Socket Type | Socket outlet with protective contact CEE 7/3 (type F) |
| Nominal Current | 16 A |
| Nominal Voltage | 250 V |
| Frequency | 50-60 Hz |
| Number of Modules | 2 |
| Number of Socket Outlets | 1 |
| Number of Active Contacts (Round) | 2 |
| Connection Type | Screwed terminal |
| Cable Section | 4-4 mm² |
| Material | Thermoplastic |
| Color | White |
| RAL Number | 9003 |
| Surface Finishing | Glossy |
| Antimicrobial Treatment | Yes - Silver compound |
| Contact Protection | Enhanced with shutters for child protection |
| Degree of Protection (IP) | IP41 |
| Degree of Impact Strength (IK) | IK04 |
| Device Width | 45 mm |
| Device Height | 45 mm |
| Device Depth | 39.5 mm |
| Built-in Depth | 31 mm |
| Minimum Box Depth | 40 mm |
| Operating Temperature Range | -5 to 35 °C |
| Storage Temperature Range | -10 to 70 °C |
| Voltage Type | AC |
| Mounting Method | Module frame with snap mounting |
| Loop Through Function | Yes |
| Halogen Free | Yes |
| Installation Options | Flush-mounting box, surface-mounting box, floor box, column module, desktop multi-outlet extension, office module, trunking |
| Standard Compliance | German Standard |
