Shop Legrand MCB DX3 6000A 2 Pole 13A Curve D Circuit Breaker | 408030 In Iraq Best Prices
Premium thermal magnetic circuit-breaker with 6000A breaking capacity, D-curve protection, and flexible installation options for residential and commercial electrical systems
The Legrand MCB DX3 6000A 2 pole 13A curve D is a thermal magnetic circuit-breaker designed to protect wiring installations against overloads and short-circuits with exceptional reliability and performance. This device features a 6000A breaking capacity according to IEC 60898-1 standard for household installations, with a D-curve tripping characteristic that provides optimal protection between 130A and 182A short-circuit thresholds (10 In to 14 In). The MCB can be supplied via copper cable, prong busbar (top or bottom side), fork busbar (bottom side), or Legrand HX3 plug busbar (top side), offering flexible installation options for various electrical configurations.
Beyond its primary protective function, this circuit-breaker serves as an effective control and isolation device for electrical installations. It features IP20 protection against solid bodies larger than 12.5mm (fingerproof) according to IEC/EN 60529 standard, ensuring safe operation in residential and commercial environments. The device is equipped with two DIN rail clamps positioned on the top and bottom, allowing independent removal even when the prong busbar is still in place. A convenient label holder enables clear circuit identification, while ON and OFF indicators on the handle (printed in red and green backgrounds respectively) provide immediate visual status confirmation.
This environmentally conscious product complies with all substance-restriction requirements and can be equipped with Legrand DX3 auxiliaries, RCD add-on modules, and various accessories for enhanced functionality. The MCB accommodates multi-wired conductor cross-sections from 1.5 to 25 mm² and solid-core conductors from 1.5 to 35 mm², with optional aluminum cable connection capability using terminal accessory n° 4 063 10. Operating across 50-60 Hz frequency range with rated voltage of 400V and impulse withstand voltage of 4kV, this circuit-breaker represents premium quality electrical protection for modern installations.
Key Features
- 6000A breaking capacity compliant with IEC 60898-1 standard for household installations
- D-curve tripping characteristic with short-circuit protection between 130A and 182A (10 In to 14 In)
- IP20 fingerproof protection against solid bodies larger than 12.5mm per IEC/EN 60529
- Flexible supply options including copper cable, prong busbar, fork busbar, and Legrand HX3 plug busbar
- Independent DIN rail mounting with top and bottom clamps for easy removal and installation
- Clear circuit identification with integrated label holder and ON/OFF status indicators
- Compatible with Legrand DX3 auxiliaries, RCD add-on modules, and various accessories
- Accommodates multi-wired conductors 1.5-25 mm² and solid-core conductors 1.5-35 mm²
- Environmentally conscious design compliant with substance-restriction requirements
- Operates across 50-60 Hz frequency with 400V rated voltage and 4kV impulse withstand capability
Technical Specifications
| Specification |
Value |
| Product Type | Thermal Magnetic Circuit-Breaker (MCB) |
| Breaking Capacity | 6000A according to IEC 60898-1 |
| Number of Poles | 2 poles (2P) |
| Rated Current | 13 Amperes |
| Tripping Characteristic | D-curve (130A-182A short-circuit threshold, 10 In to 14 In) |
| Rated Voltage | 400 Volts AC |
| Rated Insulation Voltage | 500 Volts |
| Impulse Withstand Voltage | 4 kV |
| Short-Circuit Breaking Capacity Icn at 400V | 6 kA |
| Short-Circuit Breaking Capacity Icu at 230V | 25 kA |
| Short-Circuit Breaking Capacity Icu at 400V | 10 kA |
| Frequency Range | 50-60 Hz |
| Degree of Protection | IP20 (Fingerproof) |
| Multi-wired Conductor Cross-Section | 1.5-25 mm² |
| Solid-Core Conductor Cross-Section | 1.5-35 mm² |
| Connection Type | Screwed Terminal |
| Mounting Method | DIN Rail |
| Width in Modular Spacings | 2 modules |
| Width | 35.4 mm |
| Height | 94.8 mm |
| Depth | 77.8 mm |
| Built-in Depth | 44 mm |
| Degree of Impact Strength | IK02 |
| Operating Temperature Range | -25°C to +70°C |
| Storage Temperature Range | -40°C to +70°C |
| Pollution Degree | 2 |
| Color | Grey (RAL 7035) |
| Halogen Free | Yes |
| Supply Direction | Top or Bottom |
| Concurrently Switching Neutral | No |
| Additional Equipment Possible | Yes |
| Flush-Mounted Installation | Yes |
| Reference Number | 408030 |
| EAN Code | 3245064080309 |
| Carbon Footprint (Manufacturing) | 1.791 kg CO2 eq. |
| Standard Compliance | IEC 60898-1, IEC 60947-2, IEC/EN 60529 |
