Shop Legrand DPX-IS 630 Isolating Switch 3P 630A Right Handle | 26677 In Iraq Best Prices
Professional 630A isolating switch with visible isolation, integrated padlock, and 690V AC rated voltage for industrial applications
The Legrand DPX-IS 630 Isolating Switch is a professional-grade electrical disconnection device designed for industrial and commercial applications. This three-pole isolating switch features a rated current capacity of 630 amperes at 400V and is compliant with IEC 60947-3 standards. The switch provides visible isolation with positive contact action, ensuring safe on-load circuit breaking and reliable electrical management in demanding environments.
Equipped with an integrated padlock mechanism in the handle, this isolating switch offers enhanced safety during maintenance operations. The device comes supplied with terminal shields and cage terminals for secure electrical connections. With a maximum rated operation voltage of 690V AC and a conditioned rated short-circuit current of 100 kA, this switch is suitable for use as a main switch, maintenance/service switch, safety switch, and emergency stop installation. The right-hand side rocker lever control element provides intuitive operation.
The DPX-IS 630 with release can be associated with a residual current relay with separate coil, allowing for comprehensive electrical protection. It features four change-over auxiliary contacts for flexible control configurations. The switch is suitable for floor mounting, front mounting with 4-hole configuration, and distribution board installation, making it highly versatile for various electrical cabinet and switchboard applications.
Key Features
- Rated current capacity of 630 amperes with 690V AC maximum operating voltage
- Visible isolation with positive contact action for safe on-load circuit breaking
- Integrated padlock mechanism in handle for enhanced maintenance safety
- IEC 60947-3 compliant with 100 kA conditioned rated short-circuit current
- Four change-over auxiliary contacts for flexible control configurations
- Suitable for use as main switch, maintenance switch, safety switch, and emergency stop
- Includes terminal shields and cage terminals for secure connections
- Right-hand side rocker lever control element with intuitive operation
- Versatile mounting options: floor, front 4-hole, and distribution board installation
- Compatible with residual current relay with separate coil for comprehensive protection
Technical Specifications
| Specification |
Value |
| Product Type | Isolating Switch with Release |
| Model | DPX-IS 630 |
| Number of Poles | 3 Poles (3P) |
| Rated Permanent Current | 630 A |
| Maximum Rated Operation Voltage | 690 V AC |
| Rated Operating Voltage Range | 230-690 V AC |
| Rated Short-time Withstand Current | 15 kA |
| Conditioned Rated Short-circuit Current | 100 kA |
| Rated Operation Power at AC-23, 400V | 252 kW |
| Category of Use | AC 23 A |
| Standard Compliance | IEC 60947-3 |
| Control Element Type | Rocker Lever |
| Control Element Color | Black |
| Handle Position | Right-hand side |
| Auxiliary Contacts - Change-over | 4 |
| Auxiliary Contacts - Normally Open | 0 |
| Auxiliary Contacts - Normally Closed | 0 |
| Main Circuit Connection Type | Screw Connection |
| Degree of Protection (IP) - Front | IP20 |
| Device Construction | Complete Device in Housing |
| Mounting - Floor | Yes |
| Mounting - Front 4-hole | Yes |
| Mounting - Distribution Board | Yes |
| Motor Drive | Not Available |
| Voltage Release Optional | Yes |
| Interlockable | Yes |
| Use as Main Switch | Yes |
| Use as Maintenance/Service Switch | Yes |
| Use as Safety Switch | Yes |
| Use as Emergency Stop | Yes |
| Use as Reversing Switch | No |
| Reference Number | 026677 |
| EAN Code | 3245060266776 |
| Manufacturer | Legrand |
| Accessories Included | Terminal shields, Cage terminals, Integrated padlock |
