Professional 4-pole, 63A isolating switch with visible load disconnection, integrated padlock security, 690V AC rated voltage, and compliance with IEC 60947-3 standards for industrial and commercial applications.
The Legrand DPX-IS 250 is a professional-grade isolating switch designed for on-load circuit breaking with visible isolation and positive contact action. This 4-pole, 63A isolating switch features a right-hand side rocker lever handle and is specifically engineered for industrial and commercial applications requiring reliable load disconnection. The device incorporates an integrated padlock mechanism in the handle for enhanced security and safety compliance. With a rated maximum voltage of 690V AC and rated operating voltage range of 230-690V, this isolating switch is suitable for various electrical distribution applications. The switch is equipped with cage terminals for secure connections and includes terminal shields for protection. It can be mounted on rail or plate within XL³ enclosures and is available with optional residual current relay compatibility with separate coils. This isolating switch conforms to IEC 60947-3 standards and is rated for AC 23 A category of use, making it ideal for maintenance and service switching operations.
The DPX-IS 250 with release offers exceptional performance characteristics with a rated short-time withstand current of 9 kA and a conditioned rated short-circuit current of 100 kA. It delivers 25.2 kW rated operation power at 400V AC and provides three change-over auxiliary contacts for advanced control applications. The device is fully interlockable and suitable for floor, front, and distribution board installation. Its IP20 degree of protection ensures reliable operation in standard industrial environments. The black rocker lever control element provides intuitive operation, while the complete device in housing design ensures durability and longevity. This isolating switch is an essential component for electrical systems requiring manual load isolation with positive mechanical action and visible contact separation.
The switch's robust construction and compliance with international standards make it suitable for use as a main switch, maintenance/service switch, safety switch, and emergency stop installation. The right-hand side handle orientation provides ergonomic operation in typical electrical cabinet configurations. With its comprehensive feature set and reliable performance, the Legrand DPX-IS 250 isolating switch is the preferred choice for electrical professionals and system integrators seeking dependable load isolation solutions.
Key Features
- On-load circuit breaking with visible isolation and positive contact action for safety
- Integrated padlock mechanism in handle for enhanced security and lockout compliance
- 4-pole configuration rated at 63A with 690V AC maximum operating voltage
- Three change-over auxiliary contacts for advanced control and signaling applications
- Cage terminal connections with terminal shields for secure and protected wiring
- Fully interlockable design suitable for floor, front, and distribution board mounting
- IEC 60947-3 compliant with AC 23 A category of use rating
- Right-hand side black rocker lever for ergonomic and intuitive operation
- 9 kA rated short-time withstand current and 100 kA conditioned short-circuit rating
- Suitable for use as main switch, maintenance switch, safety switch, or emergency stop installation
Technical Specifications
| Specification |
Value |
| Product Type | Isolating Switch with Release |
| Model | DPX-IS 250 |
| Number of Poles | 4 Poles |
| Rated Permanent Current | 63 A |
| Maximum Rated Voltage | 690 V AC |
| Rated Operating Voltage Range | 230-690 V AC |
| Rated Operation Power at 400V | 25.2 kW |
| Rated Short-Time Withstand Current | 9 kA |
| Conditioned Rated Short-Circuit Current | 100 kA |
| Category of Use | AC 23 A |
| Control Element Type | Rocker Lever |
| Control Element Color | Black |
| Handle Orientation | Right-Hand Side |
| Auxiliary Contacts - Change-Over | 3 |
| Auxiliary Contacts - Normally Open | 0 |
| Auxiliary Contacts - Normally Closed | 0 |
| Electrical Connection Type | Screw Connection with Cage Terminals |
| Degree of Protection (IP) | IP20 |
| Device Construction | Complete Device in Housing |
| Mounting Options | Rail or Plate Mounting in XL³ Enclosures |
| Installation Types | Floor, Front 4-hole, and Distribution Board Installation |
| Interlockable | Yes |
| Voltage Release | Optional |
| Motor Drive | Not Available |
| Standards Compliance | IEC 60947-3 |
| Reference Number | 026644 |
| EAN Code | 3245060266448 |
| Suitable as Main Switch | Yes |
| Suitable as Maintenance Switch | Yes |
| Suitable as Safety Switch | Yes |
| Suitable for Emergency Stop Installation | Yes |
