Shop Legrand DPX-IS 250 Isolating Switch 3P 160A Left-Hand | 26622 In Iraq Best Prices
Professional 160A three-pole isolating switch with integrated padlock, 690V AC rated, IEC 60947-3 compliant, ideal for industrial maintenance and safety applications
The Legrand DPX-IS 250 is a professional-grade isolating switch designed for industrial and commercial electrical installations. This three-pole isolating switch features a 160A rated permanent current capacity and is specifically engineered for on-load circuit breaking with visible isolation and positive contact action. The device incorporates an integrated padlock mechanism in the handle for enhanced safety and security during maintenance operations.
This isolating switch is fully compliant with IEC 60947-3 standards and is categorized as AC-23A usage. It is equipped with cage terminals for secure connections and comes supplied with terminal shields for added protection. The switch is suitable for multiple mounting configurations including rail mounting and plate mounting within XL³ enclosures, making it highly versatile for various electrical system designs. With a maximum rated operation voltage of 690V AC and a rated short-time withstand current of 9kA, this switch is built to handle demanding industrial applications.
The DPX-IS 250 can function as a main switch, maintenance/service switch, or safety switch, providing flexibility in system design and operation. The left-hand side rocker lever control element is finished in black and offers intuitive operation. The device is suitable for floor mounting, front mounting with 4-hole configuration, and distribution board installation, making it an ideal choice for complex electrical infrastructure requiring reliable isolation and protection.
Key Features
- Three-pole isolating switch with 160A rated permanent current capacity
- Integrated padlock mechanism in handle for enhanced security during maintenance
- IEC 60947-3 compliant with AC-23A category of use rating
- On-load circuit breaking with visible isolation and positive contact action
- Multiple mounting options: rail mounting, plate mounting, and distribution board installation
- 690V AC maximum rated operation voltage with 9kA short-time withstand current
- Cage terminal connections with supplied terminal shields
- Suitable as main switch, maintenance/service switch, or safety switch
- Left-hand side rocker lever control with black finish
- Interlockable design for enhanced operational safety
Technical Specifications
| Specification |
Value |
| Product Type | Isolating Switch - DPX-IS 250 |
| Number of Poles | 3 Poles |
| Rated Permanent Current | 160 A |
| Maximum Rated Operation Voltage | 690 V AC |
| Rated Operating Voltage Range | 230-690 V |
| Rated Short-Time Withstand Current | 9 kA |
| Conditioned Rated Short-Circuit Current | 100 kA |
| Rated Operation Power at AC-23, 400V | 64 kW |
| Category of Use | AC-23A |
| Compliance Standard | IEC 60947-3 |
| Handle Type | Left-Hand Side Rocker Lever |
| Handle Color | Black |
| Terminal Connection Type | Screw Connection with Cage Terminals |
| Degree of Protection (IP) Front Side | IP20 |
| Device Construction | Complete Device in Housing |
| Auxiliary Contacts - Normally Closed | 0 |
| Auxiliary Contacts - Normally Open | 0 |
| Auxiliary Contacts - Change-Over | 3 |
| Motor Drive | Not Available |
| Voltage Release | Optional |
| Mounting Options | Rail Mounting, Plate Mounting, Floor Mounting, Front Mounting 4-Hole, Distribution Board Installation |
| Interlockable | Yes |
| Main Switch Version | Yes |
| Maintenance/Service Switch Version | Yes |
| Safety Switch Version | Yes |
| Emergency Stop Installation Version | No |
| Reversing Switch Version | No |
| Reference Number | 026622 |
| EAN Code | 3245060266226 |
| Manufacturer | Legrand |
