Description

Shop Legrand CTX3 Motor Contactor 630A 3P 200V-240V AC | 416346 In Iraq Best Prices

Premium industrial power contactor with 630A AC-3 motor switching capacity up to 330kW, integrated 2NO+2NC contacts, 2 million mechanical operations, and full Legrand accessory compatibility for demanding motor control applications.

The Legrand CTX³ is a high-performance industrial power contactor designed for demanding motor switching and circuit control applications. This premium-grade contactor delivers exceptional reliability with a rated switching capacity of 630A at AC-3 for three-phase motors up to 330kW at 415V, and 660A at AC-1 for resistive loads. The CTX³ features integrated 2NO+2NC mirror contacts that meet IEC 60947-4-1 standards, providing superior contact reliability and performance consistency. Engineered for industrial and tertiary installations, the CTX³ combines robust construction with advanced operational capabilities. It supports M16 screw connections for the power circuit with conductor sizes from 1.25mm² to 5.5mm², and offers the same flexibility for coil and auxiliary circuits. The contactor is built to withstand up to 2 million mechanical operations and 0.5 million electrical operations, with a cycle rate of 1200 operations per hour under AC-3 conditions. The removable front cover design facilitates easy visual inspection of arc chambers and contacts, ensuring optimal maintenance and troubleshooting. The CTX³ is fully compatible with all Legrand CTX3 auxiliary devices and accessories, enabling flexible system integration. It features a 200V-240V AC or 200V-220V DC control supply voltage with a wide operational range (170-264V AC/DC). The coil is engineered for easy replacement, and the device complies with all substance-restriction requirements while being designed through environmentally conscious manufacturing processes.

Key Features

630A AC-3 rated switching capacity for three-phase motors up to 330kW at 415V
660A AC-1 resistive load capacity with superior electrical performance
Integrated 2NO+2NC mirror contacts meeting IEC 60947-4-1 standards
Up to 2 million mechanical operations and 0.5 million electrical operations
M16 screw connections with flexible conductor sizing 1.25mm² to 5.5mm²
1200 operation cycles per hour under AC-3 conditions
Removable front cover for easy arc chamber and contact inspection
Easy coil replacement design for simplified maintenance
200V-240V AC or 200V-220V DC control supply with 170-264V operating range
Full compatibility with all Legrand CTX3 auxiliary devices and accessories
Environmentally conscious manufacturing and substance-restriction compliant
Suitable for tertiary and industrial motor control installations

Technical Specifications

Specification	Value
Product Model	CTX³ Motor Contactor
Manufacturer	Legrand
Reference Number	416346
EAN Code	3414970403605
Rated Current AC-3 at 400V	630A
Rated Current AC-1 at 400V	660A
Rated Current AC-4 at 400V	400A
Motor Power Rating AC-3 at 400V	330kW
Motor Power Rating AC-4 at 400V	200kW
Control Supply Voltage AC 50Hz	200V-240V (Range: 170-264V)
Control Supply Voltage AC 60Hz	200V-240V (Range: 170-264V)
Control Supply Voltage DC	200V-220V (Range: 170-242V)
Main Circuit Contacts	3 Normally Open (3NO)
Auxiliary Contacts	2NO + 2NC (Mirror contacts)
Main Circuit Connection Type	Screw Connection
Power Circuit Screw Size	M16
Conductor Size Range	1.25mm² to 5.5mm² (Power, Coil, and Auxiliary circuits)
Mechanical Operations Endurance	Up to 2,000,000 cycles
Electrical Operations Endurance	Up to 500,000 cycles
Operation Cycles Per Hour (AC-3)	1,200 cycles/hour
Contact Type	Mirror contacts per IEC 60947-4-1
Mounting Method	Mounting plate fixing
Front Cover Design	Removable for visual inspection
Coil Design	Engineered for easy replacement
Suitable for Distribution Board	No
Environmental Compliance	RoHS Directive compliant
REACH Compliance	Manufacturer REACH Declaration
Carbon Footprint (Manufacturing)	194.750 kg CO₂ eq.
Accessory Compatibility	All Legrand CTX3 auxiliaries and accessories
Application	Tertiary and industrial motor switching and circuit control

Order Legrand CTX3 Motor Contactor 630A 3P 200V-240V AC | 416346 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
