Shop Legrand CTX3 Control Relay 2NO2NC 230V AC Motor Protection | 416826 In Iraq Best Prices
Legrand CTX3 control relay with 2NO2NC contacts at 230V AC, designed for industrial motor control with 20 million mechanical operations endurance and compact DIN-rail mounting.
The Legrand CTX3 control relay is a professional-grade switching device designed for tertiary and industrial installations. This compact relay features 2 normally open (NO) and 2 normally closed (NC) main contacts, operating at 230V AC 50/60 Hz. With exceptional endurance specifications of up to 20 million mechanical operations and 0.5 million electrical operations at AC-15 rating, this relay ensures reliable long-term performance in demanding industrial environments. The device is equipped with screw terminals capable of handling power connections from 1.25mm² to 2mm² and coil connections from 0.75mm² to 2.5mm², providing flexibility for various installation requirements.
Designed with space optimization in mind, the CTX3 features a compact form factor that mounts on standard 35mm DIN-rail (IEC 60715) or mounting plates, making it ideal for cabinet installations where space is at a premium. The relay can perform up to 1800 operation cycles per hour under AC-3 conditions, demonstrating its capability for high-frequency switching applications. Contact configuration can be extended through the use of auxiliary contact blocks, allowing customization to meet specific circuit requirements. The device complies with RoHS directives and substance-restriction requirements, manufactured through environmentally conscious processes.
This control relay is specifically engineered for motor control and protection applications in industrial settings. It features interface capability for integration with control systems and includes manual operation functionality for maintenance and testing purposes. The reliable performance, compact design, and comprehensive technical specifications make the CTX3 an excellent choice for professionals requiring dependable relay solutions for complex switching and control circuits.
Key Features
- 2 Normally Open (NO) and 2 Normally Closed (NC) main contacts for versatile switching applications
- Rated for 230V AC 50/60 Hz operation with 1.9A rated operation current at 400V
- Exceptional endurance: 20 million mechanical operations and 0.5 million electrical operations (AC-15)
- Compact DIN-rail mounting on 35mm top hat rail (IEC 60715) with space-optimized design
- Screw terminals supporting power connections 1.25-2mm² and coil connections 0.75-2.5mm²
- Extendable contact configuration through auxiliary contact blocks for custom applications
- Manual operation capability for maintenance and testing purposes
- High-frequency switching: up to 1800 operation cycles per hour (AC-3 conditions)
- RoHS compliant and environmentally conscious manufacturing process
- Interface capability for integration with control systems
Technical Specifications
| Specification |
Value |
| Product Type | Control Relay |
| Model | CTX3 |
| Manufacturer | Legrand |
| Reference Number | 416826 |
| EAN Code | 3414970407788 |
| Rated Control Supply Voltage AC 50 Hz | 195.5-253 V |
| Rated Control Supply Voltage AC 60 Hz | 195.5-253 V |
| Voltage Type | AC |
| Rated Operation Current at 400V | 1.9 A |
| Main Contacts Configuration | 2NO + 2NC |
| Auxiliary Contacts - Normally Open | 2 |
| Auxiliary Contacts - Normally Closed | 2 |
| Mounting Method | DIN-rail/Screw on 35mm top hat rail (IEC 60715) |
| Power Terminal Capacity | 1.25mm² to 2mm² |
| Coil Terminal Capacity | 0.75mm² to 2.5mm² |
| Connection Type | Screw terminals |
| Mechanical Endurance | 20 million operations |
| Electrical Endurance (AC-15) | 0.5 million operations |
| Operation Cycles per Hour (AC-3) | 1800 |
| LED Indication | No |
| Manual Operation | Yes |
| Interface Capability | Yes |
| Compliance | RoHS Directive, Substance-Restriction Requirements |
| Environmental Standard | Environmentally conscious manufacturing process |
| Application | Tertiary and Industrial Installations, Motor Control |
