Professional CTX³ control relay with 2NO+2NC contacts, 110V AC coil, and exceptional 20 million mechanical operation endurance for reliable industrial load switching and motor control applications
The Legrand CTX³ control relay (Reference 416824, EAN 3414970407764) is a professional-grade switching device designed for reliable control of inductive and resistive loads in tertiary and industrial installations. This compact relay features 2 normally open (NO) and 2 normally closed (NC) main contacts, providing versatile switching capabilities for complex control circuits. The relay operates on 110V AC supply and is engineered to deliver exceptional performance with up to 20 million mechanical operations and 0.5 million electrical operations (AC-15 rating), ensuring long-term reliability in demanding industrial environments.
The CTX³ relay offers superior installation flexibility with multiple mounting options including 35mm DIN-rail mounting (IEC 60715) and direct screw mounting on mounting plates. Its compact design optimizes space utilization within control cabinets, making it ideal for space-constrained applications. The device features screw terminals with capacity for power connections from 1.25mm² to 2mm² and coil connections from 0.75mm² to 2.5mm², accommodating various wire gauges. With manual operation capability and the option to extend contacts using CTX3 mini auxiliary contact blocks, this relay provides adaptable solutions for diverse control requirements.
The CTX³ relay is fully compliant with substance-restriction requirements and has been designed using environmentally conscious manufacturing processes. With a rated operation current of 1.9A at 400V, it handles AC-3 duty cycles up to 1800 operations per hour. This professional-grade component is backed by comprehensive technical documentation and is suitable for applications requiring high reliability, including motor control, load switching, and complex automation systems in industrial and tertiary sectors.
Key Features
- 2 Normally Open (NO) and 2 Normally Closed (NC) main contacts for versatile switching configurations
- 110V AC rated control supply voltage with 93.5-121V operational range at both 50Hz and 60Hz frequencies
- Exceptional endurance rated up to 20 million mechanical operations and 0.5 million electrical operations (AC-15)
- Compact DIN-rail mounting design (35mm IEC 60715) with optional screw terminal mounting for space optimization
- Manual operation capability with interface for extended auxiliary contact blocks to customize control circuits
- Screw terminals accommodating power connections 1.25-2mm² and coil connections 0.75-2.5mm² for flexible wiring
- AC-3 duty cycle rated for 1800 operations per hour at 1.9A nominal current at 400V
- Environmentally conscious design compliant with substance-restriction requirements (RoHS and REACH)
- Suitable for tertiary and industrial installations including motor control, load switching, and automation systems
- Backed by comprehensive technical documentation and professional-grade engineering standards
Technical Specifications
| Specification |
Value |
| Product Reference | 416824 |
| EAN Code | 3414970407764 |
| Product Family | CTX³ Control Relay |
| Rated Control Supply Voltage AC 50Hz | 110V AC (Range: 93.5-121V) |
| Rated Control Supply Voltage AC 60Hz | 110V AC (Range: 93.5-121V) |
| Voltage Type for Actuating | AC (Alternating Current) |
| Main Contacts Configuration | 2 Normally Open (NO) + 2 Normally Closed (NC) |
| Rated Operation Current (Ie) at 400V | 1.9 A |
| Number of Auxiliary Contacts (Normally Open) | 2 |
| Number of Auxiliary Contacts (Normally Closed) | 2 |
| Auxiliary Contact Connection Type | Screw Connection |
| Power Terminal Capacity | 1.25mm² to 2mm² |
| Coil Terminal Capacity | 0.75mm² to 2.5mm² |
| Mounting Method | DIN-rail (35mm IEC 60715) / Screw Terminal |
| Mechanical Endurance | Up to 20 million mechanical operations |
| Electrical Endurance (AC-15) | 0.5 million electrical operations |
| AC-3 Duty Cycle Operations per Hour | 1800 operations/hour |
| LED Indication | No |
| Manual Operation | Yes |
| Interface Support | Yes - Compatible with CTX3 mini auxiliary contact blocks |
| Environmental Compliance | RoHS Directive Compliant, REACH Declaration, Environmentally Conscious Design |
| Application Category | Tertiary and Industrial Installations |
| Suitable Load Types | Inductive and Resistive Loads |
