Shop Legrand Control Transformer Single-Phase Screw Terminal 100VA | 44263 In Iraq Best Prices
Professional single-phase control transformer with 100VA capacity, 230/400V primary and 115/230V secondary, featuring screw terminals, IP2X protection, and full compliance with international standards IEC EN 61558, UL506, and CSA C22-2.
The Legrand Control Transformer (Reference 044263) is a professional-grade single-phase isolation transformer designed for control, safety, and circuit isolation applications. This 100VA transformer features primary voltage options of 230/400V and secondary voltage outputs of 115/230V, making it ideal for industrial control systems and equipment requiring reliable voltage transformation. Built to conform to international standards including IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, and CSA C22-2 No 66, this transformer ensures compatibility with building equipment conforming to EN 61131-2, EN 60204-1, and EN 60439-1 standards.
This transformer features screw terminal connections for secure and reliable wiring, with active parts protected by a cover up to 1000VA capacity. The unit includes interference filtering (except for specific catalog numbers) and comes supplied with two coupling strips for 0V secondary/earth connections. With a compact design measuring 94mm width x 94mm height x 113mm depth, it can be directly mounted on distribution boards and is rated for IP2X protection and IK04 impact strength. The transformer has a relative short-circuit voltage of 8.71% and operates on AC voltage with Class B insulation material according to IEC 85 standards.
The instantaneous admissible power at cos φ = 0.5 is 150VA, with a rated apparent power of 100VA according to IEC and CSA standards. This reliable transformer is suitable for mounting on symmetrical rails up to 250VA and is built as an isolating transformer (not a safety or energy-saving transformer). It provides dependable performance in control circuits, signal isolation, and equipment protection applications across industrial and commercial installations.
Key Features
- Single-phase isolation transformer for control and circuit safety applications
- Primary voltage 230/400V ±15V with secondary output 115/230V
- 100VA rated apparent power with 150VA instantaneous admissible power at cos φ = 0.5
- Screw terminal connections with supplied coupling strips for secure wiring
- IP2X protection degree with IK04 impact strength rating
- Class B insulation material conforming to IEC 85 standards
- Compact dimensions 94×94×113mm suitable for distribution board mounting
- 8.71% relative short-circuit voltage for reliable circuit protection
- Interference filtering included for clean power delivery
- Full compliance with IEC EN 61558-2-2/2-4/2-6, UL506, and CSA C22-2 standards
Technical Specifications
| Specification |
Value |
| Product Type | Single-phase control and isolation transformer |
| Reference Number | 044263 |
| EAN Code | 3245060442637 |
| Primary Voltage | 230V / 400V ±15V AC |
| Secondary Voltage | 115V / 230V AC |
| Rated Apparent Power | 100 VA |
| Instantaneous Admissible Power | 150 VA at cos φ = 0.5 |
| Connection Type | Screw terminals |
| Width | 94 mm |
| Height | 94 mm |
| Depth | 113 mm |
| Degree of Protection | IP2X |
| Impact Strength Rating | IK04 |
| Insulation Class | Class B (IEC 85) |
| Relative Short-Circuit Voltage | 8.71% |
| Transformer Type | Isolating transformer (not safety or energy-saving) |
| Terminal Marking | Yes |
| Ring Core | No |
| Short-Circuit Proof | No |
| Suitable for Distribution Board | Yes |
| Suitable for PCB Mounting | No |
| Interference Filtering | Yes (except specific catalog numbers) |
| Coupling Strips Supplied | 2 coupling strips for 0V secondary/earth |
| Voltage Type | AC |
| Standards Compliance | IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, CSA C22-2 No 66 |
