Shop Legrand Control Transformer Single Phase 630VA Screw Terminal | 44267 In Iraq Best Prices
Professional single-phase control transformer 630VA with 230/400V primary and 115/230V secondary, screw terminals, IP2X protection, IK04 impact strength, and full international certification for industrial applications.
The Legrand Control Transformer and Signal Mono Screw Terminal (REF. 044267) is a premium single-phase transformer designed for control, safety, and circuit isolation applications. With a rated apparent power of 630 VA and primary voltage ratings of 230/400V AC, this transformer delivers secondary voltages of 115/230V, making it ideal for industrial control systems and signal applications. Built to conform to international standards including IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, and CSA C22-2 No 66, this transformer ensures reliable performance in demanding environments.
The transformer features screw terminal connections for secure and reliable wiring, with a relative short-circuit voltage of 3.4%. It includes two coupling strips for 0V secondary/earth connection and is supplied with interference filtering for electromagnetic compatibility. The robust construction includes active parts protected by covers up to 1000 VA, and the transformer is suitable for direct mounting on symmetrical rails up to 250 VA. With an IK04 degree of impact strength and IP2X or XXB protection rating up to 400 VA, this unit is engineered for durability and safety in industrial and commercial settings.
Designed for building equipment conforming to EN 61131-2, EN 60204-1, and EN 60439-1 standards, the Legrand Control Transformer provides instantaneous admissible power of 1600 VA at cos φ = 0.5 according to UL specifications, with 500 VA according to UL and 630 VA according to IEC and CSA standards. The compact dimensions of 132mm width × 155mm height × 175mm depth make it suitable for space-constrained installations while maintaining excellent thermal performance and reliability.
Key Features
- Single-phase control and circuit isolation transformer with 630VA rated apparent power
- Primary voltage 230/400V AC with secondary output 115/230V AC for flexible application requirements
- Screw terminal connections with two coupling strips for secure 0V secondary/earth grounding
- Compliant with international standards IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, and CSA C22-2
- IP2X or XXB protection rating with IK04 impact strength for industrial durability and safety
- Integrated interference filtering for electromagnetic compatibility (except specific categories)
- Relative short-circuit voltage of 3.4% with instantaneous admissible power of 1600VA at cos φ = 0.5
- Active parts protected by covers up to 1000VA for enhanced safety
- Suitable for direct mounting on symmetrical rails up to 250VA
- Type B insulation material classification per IEC 85 standards
Technical Specifications
| Specification |
Value |
| Product Reference | 044267 |
| EAN Code | 3245060442675 |
| Manufacturer | Legrand |
| Transformer Type | Single-phase control and circuit isolation transformer |
| Primary Voltage Options | 215V, 230V, 245V, 385V, 400V, 415V AC |
| Secondary Voltage Options | 115V AC, 230V AC |
| Rated Apparent Power | 630 VA (IEC/CSA), 500 VA (UL) |
| Instantaneous Admissible Power | 1600 VA at cos φ = 0.5 |
| Relative Short-Circuit Voltage | 3.4% |
| Insulation Material Type | Type B per IEC 85 |
| Connection Type | Screw terminal |
| Protection Rating | IP2X or XXB up to 400VA, IP XXA over 400VA |
| Impact Strength Rating | IK04 |
| Width | 132 mm |
| Height | 155 mm |
| Depth | 175 mm |
| Ring Core | No |
| PCB Mounting Compatible | No |
| Distribution Board Mounting | No |
| Terminal Marking | Yes |
| Voltage Type | AC |
| Safety Transformer | No |
| Isolating Transformer | Yes |
| Energy Saving Transformer | No |
| Short-Circuit Proof | No |
| International Standards Compliance | IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, CSA C22-2 No 66 |
| Building Equipment Standards | EN 61131-2, EN 60204-1, EN 60439-1 |
| Coupling Strips | 2 coupling strips for 0V secondary/earth (up to 1000VA) |
| Interference Filtering | Yes (except Cat.Nos 0 442 16/17/18) |
| Direct Rail Mounting | Possible on symmetrical rail up to 250VA |
