Shop Legrand Control Signal Transformer Single Phase 460V 250VA Screw | 44285 In Iraq Best Prices
Professional single-phase control transformer with 460V primary and 115V/230V secondary outputs, 250VA rated power, screw terminals, IP2X protection, and international certifications for industrial applications.
The Legrand Control and Signal Transformer model 044285 is a professional-grade single-phase transformer designed for control, safety, and circuit isolation applications. This transformer features a primary voltage of 460V and dual secondary outputs of 115V/230V, delivering 250VA of rated apparent power. Built to the highest international standards including IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, and CSA C22-2 No 66, this transformer ensures reliable performance in demanding industrial and commercial environments.
Equipped with screw terminal connections for secure and permanent installation, this transformer is ideal for building equipment conforming to EN 61131-2, EN 60204-1, and EN 60439-1 standards. The unit features integrated interference filtering to reduce electromagnetic noise and includes supplied coupling strips for 0V secondary/earth connections. With an IP2X degree of protection and IK04 impact strength rating, the transformer is suitable for mounting on distribution boards and direct fixing to symmetrical rails up to 250VA capacity.
The transformer delivers instantaneous admissible power of 430VA at cos φ = 0.5, with a relative short circuit voltage of 5.91%. Its compact dimensions (106mm width × 123mm height × 115mm depth) and efficient design make it an excellent choice for space-constrained applications. The unit comes with comprehensive technical documentation and certifications, including UL and CSA agreements, ensuring compliance with North American and international electrical standards.
Key Features
- Single-phase control and signal transformer with dual secondary voltage outputs (115V/230V)
- Primary voltage rating of 460V with 250VA rated apparent power and 430VA instantaneous admissible power
- Screw terminal connections for secure and permanent installation
- Compliant with international standards IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, and CSA C22-2 No 66
- IP2X degree of protection and IK04 impact strength rating for reliable operation
- Integrated interference filtering to minimize electromagnetic noise
- Supplied with coupling strips for 0V secondary/earth connections
- Suitable for mounting on distribution boards and symmetrical rails
- Compact dimensions (106mm × 123mm × 115mm) for space-efficient installation
- Type B insulation material with 5.91% relative short circuit voltage
Technical Specifications
| Specification |
Value |
| Product Type | Control and Signal Transformer - Single Phase |
| Manufacturer | Legrand |
| Reference Number | 044285 |
| EAN Code | 3245060442859 |
| Primary Voltage | 460V ± 20V AC (also compatible with 440V and 480V) |
| Secondary Voltage | 115V / 230V AC |
| Rated Apparent Power | 250 VA (IEC/CSA), 210 VA (UL) |
| Instantaneous Admissible Power | 430 VA at cos φ = 0.5 |
| Insulation Material Type | Type B (IEC 85) |
| Short-Circuit-Proof | No |
| Relative Short Circuit Voltage | 5.91% |
| Connection Type | Screw Terminal |
| Width | 106 mm |
| Height | 123 mm |
| Depth | 115 mm |
| Degree of Protection (IP) | IP2X |
| Impact Strength Rating (IK) | IK04 |
| Voltage Type | AC (Alternating Current) |
| Ring Core | No |
| Suitable for PCB Mounting | No |
| Suitable for Distribution Board | Yes |
| Terminal Marking | Yes |
| Built as Safety Transformer | No |
| Built as Isolating Transformer | Yes |
| Built as Energy Saving Transformer | No |
| International Standards Compliance | IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, CSA C22-2 No 66 |
| Building Equipment Standards | EN 61131-2, EN 60204-1, EN 60439-1 |
| Interference Filtering | Yes (except Cat.Nos 0442 16/17/18) |
| Coupling Strips Included | Yes - 0V secondary/earth up to 1000 VA |
| Active Parts Protection | Protected by cover up to 1000 VA |
