Single-phase isolating transformer with 460V primary and 115/230V secondary outputs, 100 VA capacity, screw terminals, IP 2X protection, and international certifications for control and signal applications.
The Legrand Control and Signal Transformer Model 044283 is a single-phase isolating transformer designed for control, safety, and circuit isolation applications. This transformer features a primary voltage of 460V and dual secondary voltages of 115V and 230V, making it versatile for various industrial and commercial control applications. With a rated apparent power of 100 VA, this transformer is built to the highest international standards including IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, and CSA C22.2 No. 66 standards.
This isolating transformer is engineered for protection and reliability with IP 2X degree of protection and IK04 impact strength rating. The transformer features screw terminal connections for secure and reliable wiring, and is supplied with 2 coupling strips for easy installation. It incorporates interference filtering to ensure clean power delivery and is suitable for mounting on distribution boards. The transformer is designed to protect active parts with covers up to 1000 VA capacity and conforms to standards EN 61131-2, EN 60204-1, and EN 60439-1 for building equipment applications.
With dimensions of 94mm width, 94mm height, and 113mm depth, this compact transformer offers an 8.74% relative short-circuit voltage rating and Type B insulation material according to IEC 85. The transformer operates on AC voltage and includes terminal marking indication for easy identification. It is not short-circuit proof but provides excellent isolation and circuit protection for control and signaling applications in industrial, commercial, and building automation environments.
Key Features
- Single-phase isolating transformer for control, safety and circuit isolation
- Primary voltage 460V with dual secondary outputs 115V and 230V
- Rated apparent power 100 VA with 150 VA instantaneous admissible power at cos φ = 0.5
- IP 2X degree of protection with IK04 impact strength rating
- Screw terminal connections with 2 supplied coupling strips
- Type B insulation material according to IEC 85 standards
- Interference filtering for clean power delivery
- Suitable for distribution board mounting
- Conforms to IEC EN 61558-2-2, 2-4, 2-6, UL506, and CSA C22.2 standards
- Compact dimensions 94mm x 94mm x 113mm with terminal marking indication
Technical Specifications
| Specification |
Value |
| Product Type | Control and Signal Isolating Transformer |
| Primary Voltage | 460V ± 20V AC (also compatible with 440V and 480V) |
| Secondary Voltage | 115V and 230V AC |
| Rated Apparent Power | 100 VA (IEC and CSA), 100 VA (UL) |
| Instantaneous Admissible Power | 150 VA at cos φ = 0.5 |
| Insulation Type | Type B according to IEC 85 |
| Relative Short Circuit Voltage | 8.74% |
| Short-Circuit Proof | No |
| Degree of Protection | IP 2X |
| Impact Strength Rating | IK04 |
| Voltage Type | AC |
| Connection Type | Screw Terminal |
| Width | 94 mm |
| Height | 94 mm |
| Depth | 113 mm |
| Ring Core | No |
| PCB Mounting | Not Suitable |
| Distribution Board Mounting | Yes |
| Terminal Marking | Yes |
| Supplied Accessories | 2 Coupling Strips (0V secondary/earth) |
| Standards Compliance | IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, CSA C22.2 No. 66, EN 61131-2, EN 60204-1, EN 60439-1 |
| Safety Features | Active parts protected by cover, Interference filtering, Isolating transformer |
| Reference Number | 044283 |
| EAN Code | 3245060442835 |
| Manufacturer | Legrand |
