Shop Legrand Control Safety Single-Phase Transformer 230-400V 24V 160VA | 44204 In Iraq Best Prices
Professional single-phase control and safety transformer with 230-400V primary input, 24V secondary output, and 160 VA rated power. Features spring connections, IP2X protection, and compliance with IEC, UL, and CSA standards for reliable circuit isolation and control applications.
The Legrand Control and Safety Transformer (REF. 044204) is a professional-grade single-phase transformer designed for control, safety, and circuit isolation applications. This transformer features a primary voltage range of 230-400V ± 15V and delivers a stable secondary output of 24V AC with a rated apparent power of 160 VA. Built according to international standards IEC EN 61558-2-2, 2-4, and 2-6, as well as UL506 and CSA C22-2 No 66, this transformer ensures compliance with building equipment standards EN 61131-2, EN 60204-1, and EN 60439-1.
This transformer is engineered with spring connection terminals for secure and reliable electrical connections. It features IP2X degree of protection and IK04 impact strength rating, making it suitable for distribution board mounting. The transformer includes interference filtering (except certain model variations) and comes equipped with a coupling strip for 0V secondary/earth connection up to 1000 VA. With active parts protected by cover up to 1000 VA, this unit provides enhanced safety for critical control applications.
The transformer demonstrates excellent performance characteristics with a relative short-circuit voltage of 7.4% and supports instantaneous admissible power at cos Ï = 0.5 of 250 VA according to UL standards. Its compact dimensions (95mm width × 128mm height × 113mm depth) and lightweight design make it ideal for space-constrained installations. This transformer is UL recognized for USA and Canada agreements and is suitable for mounting on distribution boards, offering reliable power conversion for control circuits and safety systems.
Key Features
- Single-phase control and safety transformer with dual voltage capability (230-400V input)
- Stable 24V AC secondary output with 160 VA rated apparent power
- Spring connection terminals for secure and reliable electrical connections
- IP2X degree of protection with IK04 impact strength rating
- Compliant with international standards IEC EN 61558-2-2/2-4/2-6, UL506, and CSA C22-2 No 66
- Interference filtering technology for improved performance
- Built-in coupling strip for 0V secondary/earth connection
- Direct fixing possibility on symmetrical rail up to 250 VA
- Suitable for distribution board mounting with active parts protection
- 7.4% relative short-circuit voltage for enhanced safety
Technical Specifications
| Specification |
Value |
| Product Type | Control and Safety Transformer - Single Phase |
| Reference Number | 044204 |
| EAN Code | 3245060442040 |
| Primary Voltage | 230-400V ± 15V AC (Multiple tap options: 215V, 230V, 245V, 385V, 400V, 415V) |
| Secondary Voltage | 24V AC |
| Rated Apparent Power | 160 VA (IEC/CSA), 140 VA (UL) |
| Instantaneous Admissible Power | 250 VA at cos Ï = 0.5 |
| Relative Short-Circuit Voltage | 7.4% |
| Insulation Material Class | Class B per IEC 85 |
| Degree of Protection | IP2X |
| Impact Strength Rating | IK04 |
| Connection Type | Push-in Clamp / Spring Connection |
| Voltage Type | AC (Alternating Current) |
| Width | 95 mm |
| Height | 128 mm |
| Depth | 113 mm |
| Short-Circuit-Proof | No |
| Ring Core | No |
| PCB Mounting Suitable | No |
| Distribution Board Mounting | Yes |
| Terminal Marking | Yes |
| Coupling Strip | Supplied with 0V secondary/earth coupling strip up to 1000 VA |
| Interference Filtering | Yes (except Cat.Nos 0 442 16/17/18) |
| Active Parts Protection | Protected by cover up to 1000 VA |
| Manufacturer | Legrand |
| International Standards Compliance | IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, CSA C22-2 No 66 |
| Building Equipment Standards | EN 61131-2, EN 60204-1, EN 60439-1 |
| Certifications | UL Recognized (USA and Canada Agreements) |
| Rail Mounting | Direct fixing possibility on symmetrical rail up to 250 VA |
