Description

Shop Legrand Auto-Transformer Single Phase Protected 400/230V 2kVA | 42288 In Iraq Best Prices

Professional single-phase auto-transformer with IP55 protection, 2kVA power rating, reversible 400/230V operation, and Class II insulation for industrial applications.

The Legrand Auto-Transformer Single Phase Protected 400/230V 2kVA (Reference 042288) is a professional-grade transformer designed for converting voltage levels in single-phase electrical systems. This energy-saving auto-transformer features IP55 protection rating and Class II insulation, making it suitable for industrial and commercial applications requiring reliable voltage conversion. The transformer is built according to IEC 61558-2-13 standards and offers reversibility capability, allowing operation in both 400-230V and 230-400V configurations. This auto-transformer is equipped with flexible cable terminals rated at 16 mm² on both primary and secondary sides, ensuring secure and flexible installation options. With a rated apparent power of 2000 VA, it provides efficient energy conversion with a relative short-circuit voltage of 2.6%, demonstrating excellent performance characteristics. The compact dimensions (270mm width x 150mm height x 190mm depth) allow for flexible placement in various installation environments. The transformer incorporates advanced energy-saving technology and is designed with Type B insulation material according to IEC 85 standards. Its IP55 protection degree ensures durability against dust and water ingress, making it ideal for challenging industrial environments. The product is fully compliant with RoHS Directive and REACH regulations, meeting all modern environmental and safety standards for electrical equipment.

Key Features

IP55 Protection Rating - Fully protected against dust and water ingress for harsh industrial environments
Class II Insulation - Double insulation system ensuring maximum safety and reliability
Reversible Operation - Configurable for both 400-230V and 230-400V voltage conversion
Energy-Saving Technology - Optimized efficiency with minimal power loss during transformation
IEC 61558-2-13 Compliant - Meets international standards for transformer safety and performance

Technical Specifications

Specification	Value
Product Type	Auto-Transformer, Single Phase, Protected
Primary Voltage	400V AC
Secondary Voltage	230V AC (Reversible)
Rated Apparent Power	2000 VA (2 kVA)
Primary Terminal Cable	16 mm² Flexible Cable
Secondary Terminal Cable	16 mm² Flexible Cable
Insulation Type	Class II, Type B Material (IEC 85)
Protection Degree	IP55
Relative Short-Circuit Voltage	2.6%
Width	270 mm
Height	150 mm
Depth	190 mm
Compliance Standard	IEC 61558-2-13
Short-Circuit Proof	No
Ring Core	No
PCB Mounting	Not Suitable
Distribution Board Mounting	Not Suitable
Energy Saving	Yes
Reference Number	042288
EAN Code	3245060422882

Order Legrand Auto-Transformer Single Phase Protected 400/230V 2kVA | 42288 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
