Description

Shop Legrand Auto-Transformer Single Phase Protected 400/230V 1.5kVA | 42287 In Iraq Best Prices

Professional single-phase auto-transformer with 1.5 kVA capacity, IP55 protection, reversible 400/230V operation, and energy-saving design compliant with IEC 61558-2-13 standards.

The Legrand Auto-Transformer Single Phase Protected is a professional-grade energy-saving transformer designed for single-phase electrical applications. This IP55-rated device operates at 400/230V with a rated power of 1.5 kVA, featuring reversibility capability to switch between 400-230V or 230-400V configurations. Built to IEC 61558-2-13 standards, this transformer incorporates Class II insulation with Type B insulation material, ensuring optimal safety and reliability in demanding industrial and commercial environments. The unit features flexible cable terminals rated at 16 mm² for both primary and secondary connections, enabling secure and efficient power distribution. This transformer is engineered with advanced protection mechanisms and an energy-saving design, making it ideal for applications requiring voltage conversion with enhanced efficiency. The compact dimensions of 270mm (width) x 150mm (height) x 190mm (depth) allow for flexible installation in various mounting configurations. With a relative short-circuit voltage of 2.4%, the device provides excellent voltage regulation and stability. The IP55 degree of protection ensures durability against dust and water ingress, making it suitable for challenging installation environments. The auto-transformer is specifically designed for non-short-circuit applications and is not suitable for PCB mounting or distribution board installation. Its robust construction and compliance with international standards make it a reliable choice for professional electrical installations requiring safe voltage transformation and energy management solutions.

Key Features

IP55 degree of protection against dust and water ingress
Reversible 400/230V or 230/400V configuration capability
Class II insulation with Type B insulation material
1.5 kVA rated apparent power for reliable energy conversion
Energy-saving transformer design for improved efficiency
Flexible 16 mm² cable terminals for secure connections
IEC 61558-2-13 standard compliance for safety assurance
Compact dimensions enabling flexible installation options
2.4% relative short-circuit voltage for excellent regulation
Non-short-circuit design for specialized applications

Technical Specifications

Specification	Value
Manufacturer	Legrand
Reference Number	042287
EAN Code	3245060422875
Transformer Type	Auto-transformer, Single-phase, Protected
Primary Voltage	400V
Secondary Voltage	230V
Voltage Reversibility	400-230V or 230-400V
Rated Apparent Power	1.5 kVA
Primary Cable Terminal	Flexible 16 mm²
Secondary Cable Terminal	Flexible 16 mm²
Insulation Class	Class II
Insulation Material Type	Type B
Degree of Protection	IP55
Relative Short-Circuit Voltage	2.4%
Width	270 mm
Height	150 mm
Depth	190 mm
Short-Circuit Proof	No
Safety Transformer	No
Isolating Transformer	No
Energy Saving Transformer	Yes
Ring Core	No
PCB Mounting Suitable	No
Distribution Board Suitable	No
International Standard	IEC 61558-2-13

Order Legrand Auto-Transformer Single Phase Protected 400/230V 1.5kVA | 42287 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
