Shop Legrand Arteor Multistandard Socket 2P+E Unswitched Shuttered 2 Modules Magnesium | 572623 In Iraq Best Prices
Premium multistandard 2P+E socket outlet with enhanced child safety shutters, 16A/250V rated, halogen-free thermoplastic construction in magnesium finish, featuring loop-through functionality and IP40 protection rating.
The Legrand Arteor Multistandard Socket 2P+E Unswitched Shuttered 2 Modules in Magnesium is a premium international wiring device designed for modern residential and commercial applications. This socket outlet features multistandard compatibility, making it suitable for various international electrical standards. The unswitched design provides reliable power distribution without switching functionality, while the shuttered mechanism ensures enhanced child safety by protecting against accidental contact with live contacts. The device is constructed from thermoplastic material with a matt lacquered finish in magnesium color, offering both durability and aesthetic appeal.
With a nominal current rating of 16A at 250V and frequency compatibility of 50-60 Hz, this socket is suitable for standard household and light commercial applications. The socket features enhanced contact protection and operates across a temperature range of -5°C to 50°C. The 2-module configuration allows for flexible installation in modular frame systems, with snap mounting engagement for secure installation. The device meets IP40 protection rating and IK04 impact strength, providing reliable performance in typical indoor environments.
The Arteor socket is halogen-free and complies with environmental regulations including RoHS and REACH standards. It features a loop-through function for convenient daisy-chaining of multiple outlets. The screwed terminal connection type accommodates flexible or rigid cables with a section range of 2.5-2.5 mm², ensuring secure and reliable electrical connections. This product represents Legrand's commitment to quality, safety, and international compatibility in electrical installations.
Key Features
- Multistandard socket compatibility for international electrical standards
- Enhanced child safety with shuttered contacts and protective mechanisms
- 16A/250V nominal rating suitable for residential and light commercial use
- Loop-through function for convenient daisy-chaining of multiple outlets
- Halogen-free thermoplastic material compliant with RoHS and REACH regulations
Technical Specifications
| Specification |
Value |
| Product Type | Multistandard Socket Outlet 2P+E Unswitched |
| Nominal Current | 16 A |
| Nominal Voltage | 250 V |
| Frequency | 50-60 Hz |
| Number of Modules | 2 modules |
| Material | Thermoplastic (Halogen-free) |
| Color | Magnesium (Grey) |
| Surface Finishing | Matt Lacquered |
| Device Dimensions | 45mm (W) × 45mm (H) × 35.9mm (D) |
| Built-in Depth | 26.9 mm |
| Protection Rating (IP) | IP40 |
| Impact Strength Rating (IK) | IK04 |
| Operating Temperature Range | -5°C to 50°C |
| Storage Temperature Range | -10°C to 70°C |
| Connection Type | Screwed Terminal |
| Cable Section Range | 2.5-2.5 mm² |
| Mounting Method | Module Frame with Snap Mounting |
| Number of Socket Outlets | 1 |
| Number of Active Contacts (Round) | 2 |
| Number of Active Contacts (Flat) | 2 |
| Contact Protection | Enhanced (Shuttered) |
| Loop Through Function | Yes |
| Voltage Type | AC |
| Concurrent Neutral Switching | No |
| SKU/Reference | 572623 |
| EAN Code | 3245065726237 |
| Compliance Standards | RoHS, REACH |
Order Legrand Arteor Multistandard Socket 2P+E Unswitched Shuttered 2 Modules Magnesium | 572623 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
