Professional single-phase control transformer with 40VA capacity, 230/400V primary and 115/230V secondary voltages, featuring screw terminals and full safety certifications for industrial circuit isolation and control applications.
The Legrand 044261 is a professional-grade single-phase control transformer designed for circuit isolation and control applications in industrial and commercial settings. This transformer features a rated apparent power of 40 VA with primary voltage options of 230/400V and secondary voltage outputs of 115/230V, making it ideal for safety and circuit isolation applications. The unit is constructed with screw terminal connections for secure and reliable installation, and is supplied with two coupling strips for flexible configuration. Built to conform to international standards including IEC EN 61558-2-2, 2-4, and 2-6, as well as UL506 and CSA C22-2 No 66 certifications, this transformer meets rigorous safety and performance requirements.
This control transformer is engineered with IP2X protection degree and IK04 impact strength rating, providing robust protection in demanding environments. The transformer features interference filtering capabilities (except specific catalog numbers) and can be directly fixed to symmetrical rails for installations up to 250 VA. The device incorporates active parts protected by a cover up to 1000 VA, ensuring operational safety. With a relative short-circuit voltage of 10.06% and Class B insulation material according to IEC 85 standards, this transformer delivers reliable performance and protection against electrical faults.
The compact dimensions of 94mm width, 78mm height, and 113mm depth make this transformer suitable for distribution board mounting in space-constrained installations. The unit is not short-circuit proof but offers excellent voltage regulation and stability. With terminal marking indication and AC voltage operation, this transformer is ideal for building equipment conforming to EN 61131-2, EN 60204-1, and EN 60439-1 standards. The transformer's instantaneous admissible power at cos φ = 0.5 is 50 VA, providing flexibility for various application requirements.
Key Features
- Single-phase control and circuit isolation transformer with 40VA rated apparent power
- Dual voltage configuration: Primary 230/400V AC, Secondary 115/230V AC output
- Screw terminal connections with two coupling strips for flexible installation
- IP2X protection degree with IK04 impact strength rating for robust industrial use
- Compliant with international standards IEC EN 61558-2-2, 2-4, 2-6, UL506, and CSA C22-2 No 66
- Class B insulation material with 10.06% relative short-circuit voltage
- Compact dimensions (94mm × 78mm × 113mm) suitable for distribution board mounting
- Built-in interference filtering for noise reduction
- Terminal marking indication for easy identification and installation
- Instantaneous admissible power of 50VA at cos φ = 0.5 for flexible application requirements
Technical Specifications
| Specification |
Value |
| Product Type | Single-Phase Control Transformer |
| Manufacturer | Legrand |
| Reference Number | 044261 |
| EAN Code | 3245060442613 |
| Rated Apparent Power | 40 VA |
| Primary Voltage Options | 215V, 230V, 245V, 385V, 400V, 415V (±15V tolerance) |
| Secondary Voltage Options | 115V, 230V |
| Voltage Type | AC (Alternating Current) |
| Connection Type | Screw Terminal |
| Terminal Marking | Yes - Terminal marking indication included |
| Coupling Strips | Supplied with 2 coupling strips (0V secondary/earth) |
| Insulation Class | Class B (IEC 85) |
| Relative Short-Circuit Voltage | 10.06% |
| Short-Circuit Proof | No |
| Protection Degree (IP Rating) | IP2X |
| Impact Strength (IK Rating) | IK04 |
| Width | 94 mm |
| Height | 78 mm |
| Depth | 113 mm |
| Mounting Type | Suitable for distribution board - Direct fixing on symmetrical rail up to 250 VA |
| Ring Core | No |
| PCB Mounting Suitable | No |
| Interference Filtering | Yes (except Cat.Nos 0 442 16/17/18) |
| Active Parts Protection | Protected by cover up to 1000 VA |
| Instantaneous Admissible Power (cos φ = 0.5) | 50 VA |
| Isolating Transformer | Yes |
| Safety Transformer | No |
| Energy Saving Transformer | No |
| International Standards Compliance | IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, CSA C22-2 No 66 |
| Building Equipment Standards | EN 61131-2, EN 60204-1, EN 60439-1 |
