Shop Legrand Forix Dismatic 20A Surface Mounting Socket IP2X White | 782429 In Iraq Best Prices
Premium 20A surface-mounted socket outlet with IP2X protection, Dismatic thermal MCB technology for air-conditioning control, white RAL 9003 finish, IEC standard compliant with screw terminals and impact-resistant design
The Forix Dismatic 20A Surface Mounting Socket is a premium electrical outlet system designed for modern residential and commercial applications. This high-quality socket outlet combines the elegant Forix design with Dismatic protection technology, offering reliable performance for air-conditioning system control and protection. The socket features IP2X protection rating, ensuring safety against contact with solid objects larger than 12mm, making it ideal for various installation environments.
This product is manufactured to IEC standards and comes equipped with complete mechanisms including rocker and cover plate. The Dismatic technology provides single-pole 220V/380V thermal MCB protection specifically designed for air-conditioning system control. With a rated current of 20A and operating voltage of 220V AC, it delivers consistent performance across 50-60 Hz frequency ranges. The white RAL 9003 glossy finish provides a contemporary aesthetic that complements modern interior designs.
The socket outlet features screw terminals with IP2X rating for secure and safe connections. Installation is straightforward with flush-mounted capability, and the device supports additional equipment integration. The robust construction includes an IK04 degree of impact strength, ensuring durability in demanding environments. Operating temperature range of -30 to 60°C makes it suitable for diverse climate conditions. This product represents Legrand's commitment to quality, safety, and innovative electrical solutions for both residential and commercial settings.
Key Features
- IP2X Protection Rating - Ensures safety against contact with solid objects larger than 12mm
- Dismatic 20A Thermal MCB - Specialized protection for air-conditioning system control and management
- IEC Standard Compliant - Complete mechanisms supplied with rocker and cover plate for reliable performance
- Screw Terminal Connections - IP2X rated terminals for secure and safe electrical connections
- Surface Mounting Installation - Easy flush-mounted capability with support for additional equipment integration
- White RAL 9003 Glossy Finish - Contemporary aesthetic design suitable for modern residential and commercial spaces
- IK04 Impact Resistance - Durable construction designed to withstand physical impacts in demanding environments
- Wide Operating Temperature Range - Functions reliably from -30°C to +60°C for diverse climate conditions
- 220V/380V AC Operation - Rated for 220V with 50-60 Hz frequency compatibility
- Halogen-Free Construction - Environmentally friendly design meeting modern safety and sustainability standards
Technical Specifications
| Specification |
Value |
| Product Name | Forix Dismatic Surface Mounting Socket Outlet |
| SKU/Reference | 782429 |
| EAN Code | 3245067824290 |
| Rated Current | 20 A |
| Rated Voltage | 220 V AC |
| Voltage Type | Alternating Current (AC) |
| Frequency Range | 50-60 Hz |
| Protection Rating | IP2X |
| Impact Strength Rating | IK04 |
| Number of Poles | 2 poles |
| Connection Type | Screw Terminals (IP2X rated) |
| Installation Type | Flush-mounted surface mounting |
| Built-in Depth | 65 mm |
| Width | 63 mm |
| Height | 63 mm |
| Color | White |
| RAL Number | RAL 9003 |
| Finish | Glossy |
| Operating Temperature | -30°C to +60°C |
| Storage Temperature | -30°C to +60°C |
| Halogen Content | Halogen-free |
| Standards Compliance | IEC Standard |
| Protection Type | Dismatic Thermal MCB (20A single-pole) |
| Application | Air-conditioning system control and protection |
| Additional Equipment | Supports additional equipment integration |
| Label Space | No |
| Included Components | Complete mechanisms with rocker and cover plate |
| Manufacturer | Legrand |
Order Legrand Forix Dismatic 20A Surface Mounting Socket IP2X White | 782429 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
