Description

The Fluke 80K-40 High Voltage Probe is designed to safely increase the voltage measuring range of AC/DC voltmeters to 40,000 volts peak AC or DC. It is intended for low-energy applications, such as measuring high voltages within televisions or photocopy machines. The probe features a 1000:1 voltage divider ratio, ensuring accurate readings when used with a voltmeter that has a 10 MΩ input impedance. Its high input impedance minimizes circuit loading, and the durable molded plastic housing provides user protection against high voltages. Please note, this probe is not suitable for measuring high voltages on power distribution systems.

Key Features:

Extended Voltage Range: Allows measurement of up to 40,000 volts peak AC or DC.
High Accuracy: ±1% for DC voltages from 20 kV to 35 kV at 20°C to 30°C; ±2% for voltages below 20 kV or above 35 kV.
High Input Impedance: 1000 MΩ input resistance minimizes loading on the circuit under test.
Safety Design: Molded plastic housing ensures user safety during high-voltage measurements.

Specifications:

Specification	Details
Voltage Range	1 kV to 40 kV DC or peak AC
Input Resistance	1000 MΩ
Division Ratio	1000:1
Accuracy (DC)	20 kV to 35 kV: ±1% at 20°C to 30°C; add 1% at 10°C to <20°C and >30°C to 45°C; 0 kV to <20 kV and >35 kV to 40 kV: ±2%
Accuracy (AC)	±5% at 60 Hz
Safety Compliance	Meets IEC 61010-031:1993, Type B, 40 kV DC or peak AC, 28 kV RMS AC, Overvoltage Category I
Dimensions	36 cm (14 in) length; 7.5 cm (3 in) width
Weight	Approximately 204 g (7.2 oz)

Fluke High Voltage Probe | 80K-40

Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

The Fluke 80K-40 High Voltage Probe extends the voltage measurement capability of AC/DC voltmeters up to 40,000 volts peak AC or DC, ideal for low-energy applications. Read more

SKU: 382846

The Fluke 80K-40 High Voltage Probe extends the voltage measurement capability of AC/DC voltmeters up to 40,000 volts peak AC or DC, ideal for low-energy applications.

Description

The Fluke 80K-40 High Voltage Probe is designed to safely increase the voltage measuring range of AC/DC voltmeters to 40,000 volts peak AC or DC. It is intended for low-energy applications, such as measuring high voltages within televisions or photocopy machines. The probe features a 1000:1 voltage divider ratio, ensuring accurate readings when used with a voltmeter that has a 10 MΩ input impedance. Its high input impedance minimizes circuit loading, and the durable molded plastic housing provides user protection against high voltages. Please note, this probe is not suitable for measuring high voltages on power distribution systems.

Key Features:

Extended Voltage Range: Allows measurement of up to 40,000 volts peak AC or DC.
High Accuracy: ±1% for DC voltages from 20 kV to 35 kV at 20°C to 30°C; ±2% for voltages below 20 kV or above 35 kV.
High Input Impedance: 1000 MΩ input resistance minimizes loading on the circuit under test.
Safety Design: Molded plastic housing ensures user safety during high-voltage measurements.

Specifications:

Specification	Details
Voltage Range	1 kV to 40 kV DC or peak AC
Input Resistance	1000 MΩ
Division Ratio	1000:1
Accuracy (DC)	20 kV to 35 kV: ±1% at 20°C to 30°C; add 1% at 10°C to <20°C and >30°C to 45°C; 0 kV to <20 kV and >35 kV to 40 kV: ±2%
Accuracy (AC)	±5% at 60 Hz
Safety Compliance	Meets IEC 61010-031:1993, Type B, 40 kV DC or peak AC, 28 kV RMS AC, Overvoltage Category I
Dimensions	36 cm (14 in) length; 7.5 cm (3 in) width
Weight	Approximately 204 g (7.2 oz)
