Description

The Fluke 717-1G Pressure Calibrator is designed for professionals requiring accurate pressure and current measurements in various applications. This calibrator measures pressure from -1 to 1 psi (-68.9 to 68.9 mbar) with an internal sensor, achieving 0.05% full-scale accuracy. It also measures current (mA) with 0.015% accuracy and 0.001 mA resolution, while providing a 24V loop power supply. The device features a push-button interface for easy operation, is EMI tolerant, dust and splash resistant, and includes a removable battery door for quick battery changes. Additionally, it supports pressure switch testing and allows selection among eleven different engineering units.

Key Features:

Measures pressure from -1 to 1 psi (-68.9 to 68.9 mbar) with 0.05% full-scale accuracy.
Measures current (mA) with 0.015% accuracy and 0.001 mA resolution.
Provides 24V loop power supply.
Compact and lightweight design for easy portability.
EMI tolerant, dust and splash resistant.
Removable battery door for quick battery changes.
Compatible with non-corrosive gases and liquids.
Pressure switch test function captures set, reset, and deadband values.
Selectable engineering units: psi, kPa, bar, mbar, inH₂O, cmH₂O, kg/cm², mmHg, inHg.

Specifications:

Specification	Details
Pressure Measurement Range	-1 to 1 psi (-68.9 to 68.9 mbar)
Pressure Accuracy	0.05% of full scale
Current Measurement Range	0 to 24 mA
Current Accuracy	0.015% of reading ± 0.001 mA
Pressure Connection	1/8 NPT female
Display	Backlit LCD
Power Supply	One 9V alkaline battery
Battery Life	Approximately 18 hours
Dimensions	201 mm x 98 mm x 52 mm
Weight	600 g
Operating Temperature	-10°C to 55°C
Humidity	10% to 95% non-condensing
Included Accessories	Test leads, alligator clips, user manual, soft carrying case

Fluke 717-1G Pressure Calibrator
