Description

The Fluke 700RG31 Pressure Test Gauge offers reliable and accurate pressure measurements in the range of -14 to 10,000 PSI (up to 690 Bar). This rugged gauge is ideal for both field and laboratory calibration tasks. It features a large digital display with a 20-segment bar graph for easy readings. The gauge is CSA and ATEX certified, making it safe for use in hazardous environments. Its robust design ensures long-lasting performance in demanding industrial conditions.

Key Features:

Pressure Range: -14 to 10,000 PSI (-0.97 to 690 Bar)
High Accuracy: ±0.05% FS for positive pressure; ±0.1% FS for vacuum
Rugged Design: Built for industrial and laboratory environments
Digital Display: 5½-digit display with 20-segment bar graph
Battery Life: Up to 2000 hours on slow sample rate

Specifications:

Specification	Details
Range	-14 to 10,000 PSI (-0.97 to 690 Bar)
Resolution	1 PSI (0.01 Bar)
Accuracy	±0.05% FS (positive), ±0.1% FS (vacuum)
Burst Pressure	20,000 PSI (1,035 Bar)
Pressure Connection	¼" NPT male
Display	5½ digits, 0.65-inch display, 20-segment bar graph
Power Supply	3 x AA alkaline batteries
Battery Life	Up to 2000 hours
Dimensions	5 x 4.5 x 1.5 in (12.7 x 11.4 x 3.7 cm)
Weight	0.5 kg

Fluke Pressure Test Gauge 690 bar | 700RG31

Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

High-precision pressure gauge designed to measure pressures from -14 to 10,000 PSI, suitable for industrial calibration applications with reference-class accuracy. Read more

SKU: 4353646

High-precision pressure gauge designed to measure pressures from -14 to 10,000 PSI, suitable for industrial calibration applications with reference-class accuracy.

Description

The Fluke 700RG31 Pressure Test Gauge offers reliable and accurate pressure measurements in the range of -14 to 10,000 PSI (up to 690 Bar). This rugged gauge is ideal for both field and laboratory calibration tasks. It features a large digital display with a 20-segment bar graph for easy readings. The gauge is CSA and ATEX certified, making it safe for use in hazardous environments. Its robust design ensures long-lasting performance in demanding industrial conditions.

Key Features:

Pressure Range: -14 to 10,000 PSI (-0.97 to 690 Bar)
High Accuracy: ±0.05% FS for positive pressure; ±0.1% FS for vacuum
Rugged Design: Built for industrial and laboratory environments
Digital Display: 5½-digit display with 20-segment bar graph
Battery Life: Up to 2000 hours on slow sample rate

Specifications:

Specification	Details
Range	-14 to 10,000 PSI (-0.97 to 690 Bar)
Resolution	1 PSI (0.01 Bar)
Accuracy	±0.05% FS (positive), ±0.1% FS (vacuum)
Burst Pressure	20,000 PSI (1,035 Bar)
Pressure Connection	¼" NPT male
Display	5½ digits, 0.65-inch display, 20-segment bar graph
Power Supply	3 x AA alkaline batteries
Battery Life	Up to 2000 hours
Dimensions	5 x 4.5 x 1.5 in (12.7 x 11.4 x 3.7 cm)
Weight	0.5 kg
