ملتيميتر فلوك 177 الرقمي بتقنية RMS الحقيقية

Description

The Fluke 177 True-RMS Digital Multimeter provides the essential features needed for troubleshooting and repairing electrical and electronic systems. It delivers accurate True-RMS AC voltage and current measurements, as well as frequency, capacitance, resistance, continuity, and diode testing. The multimeter offers both manual and automatic ranging, Display Hold, Auto Hold, and Min/Max-average recording to enhance productivity. Safety-rated for industrial use, it meets CAT III 1000 V and CAT IV 600 V standards. The ergonomic design includes an integrated protective holster, and the device allows for closed-case calibration through the front panel.

Specification:

Specification	Details

True-RMS Measurement

Yes

Voltage Range

Up to 1000 V AC/DC

Current Range

Up to 10 A AC/DC

Frequency Range

0.01 Hz to 100 kHz

Capacitance Range

1 nF to 10,000 µF

Resistance Range

0.1 Ω to 50 MΩ

Safety Compliance

CAT III 1000 V, CAT IV 600 V

Backlit Display

Yes

Operating Temperature

-10 °C to 50 °C (14 °F to 122 °F)

Storage Temperature

-40 °C to 60 °C (-40 °F to 140 °F)

Battery

9V Alkaline; ~200 hours of battery life

Dimensions

187 x 85 x 45 mm (7.36 x 3.35 x 1.77 inches)

Weight

420 g (0.93 lbs)

Fluke 177 True-RMS Digital Multimeter

Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

High-precision True-RMS digital multimeter for accurate measurement of voltage, current, frequency, capacitance, and more. Read more

SKU: 1592874

High-precision True-RMS digital multimeter for accurate measurement of voltage, current, frequency, capacitance, and more.

The Fluke 177 True-RMS Digital Multimeter provides the essential features needed for troubleshooting and repairing electrical and electronic systems. It delivers accurate True-RMS AC voltage and current measurements, as well as frequency, capacitance, resistance, continuity, and diode testing. The multimeter offers both manual and automatic ranging, Display Hold, Auto Hold, and Min/Max-average recording to enhance productivity. Safety-rated for industrial use, it meets CAT III 1000 V and CAT IV 600 V standards. The ergonomic design includes an integrated protective holster, and the device allows for closed-case calibration through the front panel.

Specification:
