Professional-grade 12-Point SAE Flank Drive® offset box wrench with 60° deep offset for accessing recessed fasteners. Chrome finish, ASME®/ANSI® certified, ideal for aviation, aerospace, and industrial applications.
The Snap-on 3/8–7/16" 12-Point SAE Flank Drive® Short 60° Deep Offset Box Wrench (Model XSO1214A) is a professional-grade hand tool designed for accessing recessed fasteners in tight spaces. This premium wrench features a deeply offset head at 60° to the handle, providing superior access to hard-to-reach bolts and nuts in confined areas. The 12-Point Flank Drive® configuration delivers exceptional strength and turning power while minimizing fastener rounding, making it ideal for professional mechanics and technicians in aviation, aerospace, automotive, and industrial applications.
Crafted with precision engineering and chrome finish, this short-handle offset box wrench meets ASME®/ANSI® B107.100 standards for quality and performance. The compact 4-13/16" length combined with the deep 60° offset design makes it an essential tool for complex mechanical work where standard wrenches cannot reach. The head dimensions of 17/32–5/8" outside diameter and 1/4–9/32" depth ensure compatibility with standard SAE fastener sizes while maintaining structural integrity under demanding conditions.
This Snap-on Flank Drive® wrench is built to withstand professional use and provides reliable performance for years. Whether you're working on aircraft engines, power generation equipment, or heavy-duty machinery, this offset box wrench delivers the access and power needed for precise fastener engagement.
Key Features
- 60° deep offset head design for improved access to recessed fasteners in confined spaces
- 12-Point Flank Drive® configuration for maximum strength and turning power
- Professional-grade chrome finish for corrosion resistance and durability
- Short handle design (4-13/16" length) for compact tool control and maneuverability
- ASME®/ANSI® B107.100 certified for quality and performance standards
- Engineered to minimize fastener rounding and slipping
- Suitable for aviation, aerospace, automotive, and industrial maintenance applications
Technical Specifications
| Specification |
Value |
| Model Number | XSO1214A |
| Size (SAE) | 3/8–7/16" |
| Point Configuration | 12-Point |
| Offset Angle | 60° Deep Offset |
| Handle Style | Short Handle |
| Length (Dimension C) | 4-13/16 inches |
| Outside Diameter (Dimension A) | 17/32–5/8 inches |
| Head Depth (Dimension B) | 1/4–9/32 inches |
| Finish | Chrome |
| Drive Type | Flank Drive® |
| Standard Compliance | ASME®/ANSI® B107.100 |
| Material | Alloy Steel |
| Fastener Type | SAE (Standard American Specifications for Fasteners) |
| Warranty | Snap-on Limited Lifetime Warranty |
