Shop Legrand Eloe BS 13A Switched Socket with USB Type-A Charger White | 618058 In Iraq Best Prices
Eloe 13A switched socket with integrated 2.4A USB A charger, British Standard compliant, featuring safety shutters, screw terminals, and glossy white finish for residential and commercial use.
The Eloe 1 gang British Standard 13A single pole switched socket with integrated USB A charger is a modern electrical solution that combines traditional power outlet functionality with contemporary charging capabilities. This innovative device features a 2P+E configuration operating at 250V with a 2.4A USB A charger, making it ideal for homes and offices where both conventional appliances and mobile devices need to be powered simultaneously. The socket is delivered as a complete set with all necessary components and mounting hardware for both flush and surface installations.
Designed with safety and convenience in mind, the Eloe socket incorporates safety shutters to maximize child protection and features screw-type terminals for secured and enhanced electrical contacts. The device boasts marked terminals for easy identification during installation and maintenance, ensuring professional-grade reliability. With a glossy white finish and squarrish design featuring a full rocker plate aesthetic, this socket provides both functional excellence and contemporary visual appeal that complements any interior design.
The quick and easy plate clipping system allows for rapid installation, while the combination of power socket and USB charger on a single unique device eliminates the need for multiple outlets. Operating at 50-60 Hz frequency with an IP20 protection rating and IK04 impact strength rating, this socket is suitable for residential and light commercial applications. The device includes overvoltage protection and fault current protection features, ensuring safe operation and protection of connected devices.
Key Features
- 2P+E British Standard 250V configuration with 2.4A USB A charger for dual-purpose charging
- Safety shutters for maximum child protection and enhanced electrical safety
- Screw-type terminals with marked identification for secure and reliable connections
- Quick and easy plate clipping system enabling rapid professional installation
- Combination power socket and USB charger on single device eliminating multiple outlets
- Overvoltage and fault current protection for connected device safety
- Glossy white finish with squarrish design and full rocker plate aesthetic
- Suitable for flush and surface mounting with included hardware for both installation types
- IP20 protection rating and IK04 impact strength rating for residential applications
- Operating temperature range 0-35°C with 50-60 Hz frequency compatibility
Technical Specifications
| Specification |
Value |
| Standard | British Standard |
| Voltage | 250V AC |
| Current Rating | 13A (socket) + 2.4A (USB) |
| Frequency | 50-60 Hz |
| Number of Socket Outlets | 1 (13A with switch) |
| USB Ports | 1x USB-A |
| USB Output Power | 15W |
| Connection Type | Screw terminals (1-4 mm²) |
| Protective Contact | Flat (2P+E) |
| Material | Thermoplastic (Halogen-free) |
| Colour | Glossy White |
| Mounting Method | Flush-mounted with screw fastening |
| Device Dimensions | 86mm (W) x 86mm (H) x 32.7mm (D) |
| Built-in Depth | 18.4mm |
| Minimum Box Depth | 35mm |
| Protection Rating | IP20 |
| Impact Strength Rating | IK04 |
| Operating Temperature | 0-35°C |
| Storage Temperature | -10-70°C |
| Safety Features | Overvoltage protection, Fault current protection, Safety shutters |
| Switch Type | Single pole with on/off switch |
| Terminal Marking | Yes, marked for easy identification |
| Assembly Arrangement | Basic element with full cover plate (2 modules) |
| Reference Number | 618058 |
| EAN Code | 3414972264907 |
