Dual-function 1 gang British Standard 13A socket with integrated 2.4A USB A charger, safety shutters, screw terminals, and glossy white finish for modern electrical installations.
The Eloe 1 Gang British Standard 13A Unswitched Socket with USB A charger combines traditional power delivery with modern charging convenience. This dual-function device integrates a standard 2P+E British socket rated at 250V with a 2.4A USB A charging port, providing users with both conventional electrical outlets and contemporary device charging capabilities in a single, elegant installation. The socket features screw-type terminals that ensure secured and enhanced contact integrity, making it ideal for both residential and commercial applications where reliable power distribution is essential.
Designed with safety and ease of installation in mind, the Eloe socket incorporates safety shutters to maximize child protection and prevent accidental contact with live components. The complete set includes mounting hardware compatible with both plastic and metal flush-mounting boxes, facilitating quick and straightforward installation. The device features a glossy white finish with a distinctive squarrish shape and full rocker plate aesthetic, providing a contemporary appearance that complements modern interior designs. Marked terminals enable easy identification during installation and maintenance, reducing potential errors and installation time.
The Eloe socket delivers 15W of USB output power, sufficient for charging most portable devices simultaneously with standard electrical usage. With overvoltage protection and fault current protection built-in, this device safeguards connected equipment from electrical anomalies. The socket maintains a compact profile with dimensions of 86mm x 86mm x 30.2mm, suitable for standard flush-mounted installation boxes with minimum 35mm depth. Operating across 50-60Hz frequencies and rated for IP20 protection with IK04 impact strength, this versatile socket represents an ideal solution for modern electrical installations requiring integrated power and charging solutions.
Key Features
- 2P+E British Standard socket with 250V, 13A rating combined with 2.4A USB A charging port
- Safety shutters for maximum child protection and prevention of accidental contact
- Screw-type terminals with marked identification for secure and enhanced contact integrity
- Quick and easy plate clipping system for fast installation in flush and surface mounting boxes
- 15W USB output power delivery suitable for simultaneous charging of portable devices
- Built-in overvoltage and fault current protection for equipment safeguarding
- Glossy white finish with distinctive squarrish shape and full rocker plate aesthetic
- Compact dimensions of 86mm x 86mm x 30.2mm compatible with standard mounting boxes
- IP20 protection rating with IK04 impact strength for reliable durability
- Halogen-free plastic construction meeting modern safety and environmental standards
Technical Specifications
| Specification |
Value |
| Product Type | 1 Gang British Standard Socket with USB Charger |
| Voltage Rating | 250V AC |
| Current Rating | 13A (Socket), 2.4A (USB) |
| Frequency | 50-60 Hz |
| USB Ports | 1x USB A, 15W output power |
| Connection Type | Screw-type terminals, 1-4mm² cable capacity |
| Dimensions | 86mm (W) x 86mm (H) x 30.2mm (D) |
| Mounting Depth | Minimum 35mm built-in installation box depth, 18.4mm built-in depth |
| Protection Rating | IP20 (Ingress Protection), IK04 (Impact Strength) |
| Material | Halogen-free thermoplastic |
| Color | Glossy White |
| Safety Features | Safety shutters, overvoltage protection, fault current protection |
| Operating Temperature | 0-35°C |
| Storage Temperature | -10-70°C |
| Installation Method | Flush-mounted with screw fastening |
| Mounting Compatibility | Plastic and metal flush boxes, surface mounting boxes |
| Certification | British Standard compliant, RoHS certified, REACH compliant |
| SKU | 618057 |
| EAN Code | 3414972264686 |
| Brand | Legrand - Eloe Range |
