Premium dual Euro-US switched socket with 16A/250V rating, safety shutters, screw terminals, and glossy white finish for safe and reliable electrical connectivity
The Eloe 1 Gang 2x2 Pole Switched Euro-US Socket in glossy white finish is a premium multi-standard electrical outlet designed for modern residential and commercial applications. This dual-socket configuration features two independent 2-pole Euro-US standard outlets, each rated at 16A and 250V, making it ideal for connecting multiple devices simultaneously. The socket is equipped with screw-type terminals for enhanced contact security and reliability, ensuring safe and stable electrical connections for various cable gauges.
This Legrand product combines functionality with safety, featuring integrated safety shutters to maximize child protection and prevent accidental contact with live parts. The quick and easy plate clipping system allows for rapid installation in both flush-mounted and surface-mounted applications. The device comes complete with a protective shell to guard against paint and dust during the installation phase, along with pre-packaged screws compatible with both plastic and metal mounting boxes. The squarrish design with full rocker plate aesthetic provides a contemporary appearance that complements modern interior design.
The Eloe socket is manufactured from halogen-free thermoplastic material, meeting environmental and safety standards. With an impact strength rating of IK04 and IP20 protection degree, it is suitable for indoor use in standard domestic and light commercial environments. Terminal markings facilitate easy identification during installation, while the eject mechanism ensures convenient plug removal. Operating temperature range of -5 to 50°C ensures reliable performance across various climatic conditions.
Key Features
- Dual 2x2 Pole Euro-US standard outlets for simultaneous device connectivity
- 16A/250V rated capacity with 50-60Hz frequency compatibility
- Integrated safety shutters for enhanced child protection and accident prevention
- Screw-type terminals with marked identification for secure and easy installation
- Quick and easy plate clipping system for rapid flush and surface mounting
- Halogen-free thermoplastic construction meeting environmental standards
- IK04 impact resistance and IP20 protection degree for indoor use
- Complete installation package with protective shell and mounting screws
- Eject mechanism for convenient plug removal and replacement
- Contemporary squarrish design with full rocker plate aesthetic
Technical Specifications
| Specification |
Value |
| Product Model | Multi-standard socket with 2x2 Pole Euro-US configuration |
| Reference Number | 618090 |
| EAN Code | 3414972264440 |
| Rated Current | 16 A |
| Rated Voltage | 250 V |
| Frequency | 50-60 Hz |
| Number of Socket Outlets | 2 |
| Number of Modules | 2 |
| Connection Type | Screwed terminal |
| Cable Section Range | 1-4 mm² |
| Material | Halogen-free thermoplastic |
| Color | Glossy White |
| RAL Number (Similar) | 9003 |
| Device Width | 86 mm |
| Device Height | 86 mm |
| Built-in Depth | 22.5 mm |
| Minimum Box Depth | 35 mm |
| Mounting Method | Flush-mounted or surface-mounted |
| Type of Fastening | Mounting with screw |
| Protection Degree (IP) | IP20 |
| Impact Strength (IK) | IK04 |
| Operating Temperature Range | -5 to 50 °C |
| Storage Temperature Range | -10 to 70 °C |
| Voltage Type | AC |
| With Safety Shutters | Yes |
| With Eject Mechanism | Yes |
| Terminal Marking | Yes |
| Protective Contact | None |
| Number of Active Contacts (Round) | 4 |
| Number of Active Contacts (Flat) | 4 |
| Overvoltage Protection | No |
| Fault Current Protection | No |
| Antimicrobial Treatment | No |
| Smart Home Compatible | No (Apple HomeKit, Amazon Alexa, Google Assistant not supported) |
| Recommended Usage | Indoor use only |
