The EGA Master Drop Head Threader 63025 is a precision manual threading head designed to deliver high-quality and accurate pipe threads. It is specially manufactured with internal machining of the aluminium cover, ensuring that the four combs remain perfectly concentric for consistent and reliable threading results.
This model allows easy and smooth manual threading while maintaining excellent control and stability. The longer neck design improves positioning, reduces vibrations, and enhances thread quality while facilitating easy extraction of the head from the ratchet.
The drop head includes interchangeable dies to suit specific threading needs and is compatible with BSPT thread standards. Built with high-quality materials and professional-grade finishing, this tool is ideal for plumbing, mechanical installations, and industrial maintenance applications.
Specifications & Features
-
Model: 63025
-
Type: Drop Head Threader
-
Thread Type: BSPT
-
Pipe Range (O.D.): 1/2″ – 1″
-
Die System: Interchangeable combs
-
Head Body Material: Malleable cast iron
-
Lid Material: Aluminium
-
Comb Material: Special steel
-
Comb Hardness: 58–62 HRC
-
Rattle Material: Aluminium alloy
-
Reducer Material: Aluminium
-
Finish (Head): Semi-textured black epoxy powder
-
Finish (Rattle): Red epoxy powder, RAL 2002
-
Application: Manual pipe threading with high precision
