The Dorland Clamp Meter DT95 EX is a rugged, intrinsically safe clamp-style multimeter designed for use in hazardous and explosive environments. It offers precise true RMS measurements for both DC current up to 1000 A and AC current up to 3000 A with a flexible coil. The device also measures voltage, resistance, continuity, capacitance, frequency, duty cycle, temperature, and diode functions.
Equipped with a built-in flashlight, non-contact AC voltage detection, and Bluetooth connectivity for real-time data transfer, it ensures convenience and safety in industrial applications. A large 50,000-count backlit LCD provides clear readings even in dim environments. Durable, portable, and certified for intrinsically safe operation, this clamp meter is ideal for outdoor work, pipeline inspections, and industrial maintenance.
Features
-
Intrinsically safe and explosion-proof certification
-
True RMS clamp measurement up to 1000 A DC and 3000 A AC
-
Wide range of functions: voltage, resistance, continuity, capacitance, frequency, duty cycle, temperature, diode
-
Built-in flashlight and non-contact AC voltage detector
-
Bluetooth connectivity for mobile data transfer and storage
-
Large 50,000-count backlit LCD display
-
Rugged, portable, and drop-resistant design
Specifications Table
| Specification |
Details |
| Safety Certification |
Ex ib IIC T4 Gb / Ex ib IIIC T130 °C Db |
| IP Rating |
IP20 |
| DC Current Measurement |
Up to 1000 A DC, ±(2.5%+5) |
| AC Current Measurement |
Up to 3000 A AC (flexible coil), ±(2.5%+5) |
| DC Voltage Measurement |
Up to 1000 V, ±(0.2%+5) |
| AC Voltage Measurement |
Up to 750 V, ±(1.0%+9) |
| Other Functions |
Resistance, capacitance, frequency, duty cycle, temperature, diode, continuity |
| Display |
50,000-count backlit LCD with status indicators |
| Measurement Rate |
2 readings per second |
| Battery |
9 V battery with auto power-off (~30 mins) |
| Size & Weight |
230 × 76 × 40 mm; 315 g |
| Environmental Conditions |
Operating: 5–40 °C; Storage: –20–60 °C; Humidity up to 80% at 31 °C |
| Certificate No. |
SYEx25.01128 |
| Model |
Clamp Meter DT95 EX |
