Shop INGCO DCM610001 Digital AC Clamp Meter Professional Electrical Testing Tool In Iraq Best Prices
Professional digital AC clamp meter with TRUE RMS 6000 counts display, measuring AC current up to 1200A, comprehensive voltage and resistance ranges, temperature measurement, diode testing, and advanced diagnostic functions for electrical professionals.
The DCM610001 Digital AC Clamp Meter is a professional-grade electrical testing instrument designed for accurate measurement of AC current, voltage, resistance, capacitance, and frequency. This versatile multimeter features a high-resolution VA color display screen with TRUE RMS technology capable of 6000 counts, making it ideal for electricians, technicians, and maintenance professionals. The device offers multiple measurement ranges including AC current up to 1200A, DC voltage up to 1000V, and AC voltage up to 750V, providing comprehensive electrical diagnostics in both residential and industrial applications.
Equipped with advanced measurement capabilities, this clamp meter includes diode testing, phase function analysis, low impedance mode (Lowz), and low-pass filter (LPF/VFD) features for accurate readings in complex electrical environments. The temperature measurement range extends from -40°C to 1000°C, making it suitable for thermal diagnostics. Additional features include data hold function, low battery indication, automatic power-off to conserve battery life, and inrush current measurement capability. The meter comes pre-installed with three AAA LR03 batteries and is securely packaged in a protective plastic box for safe transport and storage.
Designed with user convenience in mind, the DCM610001 combines durability, accuracy, and ease of use. Its comprehensive measurement ranges and advanced diagnostic functions make it an essential tool for professional electrical work, equipment maintenance, troubleshooting, and quality control applications. Whether you're working on HVAC systems, industrial machinery, or electrical installations, this digital clamp meter delivers reliable performance and precise measurements.
Key Features
- TRUE RMS 6000 counts digital display with VA color screen for accurate readings
- AC current measurement ranges: 60A, 600A, and 1200A for versatile applications
- Comprehensive voltage measurement: DC 600mV-1000V and AC 600mV-750V
- Advanced functions including diode test, phase function, low impedance mode (Lowz), and low-pass filter (LPF/VFD)
- Temperature measurement range from -40°C to 1000°C with inrush current capability
- Data hold function for capturing and retaining measurement values
- Automatic power-off feature to extend battery life
- Pre-installed with 3 AAA LR03 batteries included
- Low battery indication alert for timely battery replacement
- Resistance measurement: 600Ω to 60MΩ across multiple ranges
- Capacitance measurement: 60nF to 60mF with multiple range options
- Frequency measurement: 10Hz to 10MHz for complete electrical diagnostics
- Protective plastic box packaging for safe storage and transport
Technical Specifications
| Specification |
Value |
| Model Number | DCM610001 |
| Display Type | VA Color Display Screen with TRUE RMS Technology |
| Display Resolution | 6000 Counts |
| AC Current Ranges | 60A, 600A, 1200A |
| DC Voltage Ranges | 600mV, 6V, 60V, 600V, 1000V |
| AC Voltage Ranges | 600mV, 6V, 60V, 600V, 750V |
| Resistance Ranges | 600Ω, 6kΩ, 60kΩ, 600kΩ, 6MΩ, 60MΩ |
| Capacitance Ranges | 60.00nF, 600.0nF, 6.000uF, 60.00uF, 600.0uF, 6.000mF, 60.00mF |
| Frequency Ranges | 10Hz, 100Hz, 1kHz, 10kHz, 100kHz, 1MHz, 10MHz |
| Temperature Measurement Range | -40.0°C to 1000.0°C (-40.0°F to 1832.0°F) |
| Special Features | Data Hold, Lowz Mode, LPF (VFD), Inrush Current, Phase Function, Diode Test |
| Battery Type | 3 x AAA LR03 Batteries (Included) |
| Low Battery Indication | Yes |
| Auto Power-Off | Yes |
| Packaging | Protective Plastic Box |
| Category | Hand Tools - Digital Multimeters |
| Warranty | Standard INGCO Warranty |
Order INGCO DCM610001 Digital AC Clamp Meter Professional Electrical Testing Tool at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
