The DCK KDJZ20160i TYPE EM 20V Brushless Cordless Hammer Drill Driver is a heavy-duty cordless drill designed for professional drilling, screwdriving, and hammer drilling applications. Powered by the DCK 20V MAX battery platform and a high-performance brushless motor, it delivers up to 160Nm maximum torque for demanding work in wood, steel, brick walls, installation jobs, maintenance, and construction tasks.
This cordless hammer drill driver features a 13mm ratchet metal chuck for secure bit holding and long-term durability. With 19+2 torque settings, users can adjust the tool accurately for different fastening, drilling, and hammer drilling applications. The two-speed gearbox provides low-speed control from 0 to 500 RPM for screwdriving and high-torque work, while the second gear reaches up to 2100 RPM for faster drilling.
For improved safety and user comfort, the KDJZ20160i includes DSC safety control technology, which helps protect the machine and user if the drill bit gets stuck. It also features an LED working light for better visibility in dark areas and a rubberized handle for a more comfortable grip. As the TYPE EM package, this version includes two 4.0Ah battery packs, a 4A charger, auxiliary handle, driver bit, belt clip, and plastic carrying case, making it a complete ready-to-use kit.
Features:
- Brushless motor for higher efficiency, stronger performance, and longer service life
- 160Nm maximum torque for heavy-duty drilling and fastening tasks
- 20V MAX cordless battery platform for flexible work without cable restrictions
- 13mm ratchet metal chuck for strong and durable bit holding
- 19+2 torque settings for accurate control across different applications
- Two-speed gearbox for high-torque screwdriving and high-speed drilling
- No-load speed of 0 to 500 RPM in first gear and 0 to 2100 RPM in second gear
- Rated impact frequency up to 33600 impacts per minute for masonry drilling
- Drilling capacity up to 13mm in steel, 16mm in brick wall, and 65mm in wood
- DSC safety control technology helps protect the user and tool if the bit gets stuck
- LED working light improves visibility in low-light work areas
- Rubberized handle provides a comfortable and secure grip
- TYPE EM kit includes two 4.0Ah batteries, 4A charger, and plastic case
Specifications:
| Specification |
Details |
| Brand |
DCK |
| Model |
KDJZ20160i |
| Type |
TYPE EM |
| Product Type |
Cordless Brushless Hammer Drill Driver |
| Power Source |
20V MAX Lithium-ion Battery |
| Package Style |
Kit |
| Battery Included |
Yes |
| Battery Quantity |
2 Batteries |
| Battery Capacity |
4.0Ah |
| Charger Included |
Yes |
| Charger Rating |
4A |
| Max Chucking Capacity |
13mm |
| No-load Speed Low |
0 to 500 RPM |
| No-load Speed High |
0 to 2100 RPM |
| Rated Impact Frequency |
0 to 33600 impacts per minute |
| Max Drilling Diameter in Steel |
13mm |
| Max Drilling Diameter in Brick Wall |
16mm |
| Max Drilling Diameter in Wood |
65mm |
| Torque Settings |
19+2 |
| Max Torque |
160Nm |
| Motor Type |
Brushless Motor |
| Chuck Type |
13mm Ratchet Metal Chuck |
| Safety Technology |
DSC Safety Control |
| Working Light |
LED Working Light |
| Handle |
Rubberized Handle |
| Net Weight |
Approx. 2.4 kg with battery |
What is in the Box:
- 1 x DCK KDJZ20160i TYPE EM 20V Brushless Cordless Hammer Drill Driver
- 2 x 4.0Ah Battery Packs
- 1 x 4A Battery Charger
- 1 x Auxiliary Handle
- 1 x Driver Bit
- 1 x Belt Clip
- 1 x Plastic Carrying Case
