Description

The CMC S23 is a compact and versatile hydraulic spider lift designed for tasks requiring precision and reach in confined spaces. With a maximum working height of 23 meters and a horizontal outreach of 12.4 meters, it offers exceptional performance for various applications, including building maintenance, tree care, and installations in challenging environments.

Key Features and Benefits:

  • Double Pantograph Design: Features a double pantograph with articulated arms and jib, providing excellent performance without outreach-limiting devices.

  • Compact Dimensions: Allows access through standard doorways and operation in confined spaces.

  • Self Control System: Equipped with CMC's Self Control System for automatic control of stabilization, maneuvering speed, automatic closure of the aerial part, and collision prevention.

  • Versatile Power Options: Available with various engine configurations, including petrol, diesel, and electric, to suit different work environments.

  • Easy Transport: Lightweight design enables transportation on trailers or small vans.

Specifications:

  • Maximum Working Height: 23 meters

  • Maximum Outreach: 12.4 meters

  • Platform Height: 21 meters

  • Basket Load Capacity: 200 kg

  • Basket Dimensions: 1.4 x 0.7 x 1.1 meters

  • Basket Rotation: ±90° (optional)

  • Turret Rotation: ±355° (710° continuous)

  • Total Weight: 3,000 kg

Read more

Product form

CMC S23 Hydraulic Spider Lift – 23m Working Height, 12.4m Outreach

CMC

Compact 23m hydraulic spider lift with 12.4m outreach, ideal for indoor and outdoor applications in confined spaces. Read more

    SKU: S23-CMC

      Compact 23m hydraulic spider lift with 12.4m outreach, ideal for indoor and outdoor applications in confined spaces.

      Description

      The CMC S23 is a compact and versatile hydraulic spider lift designed for tasks requiring precision and reach in confined spaces. With a maximum working height of 23 meters and a horizontal outreach of 12.4 meters, it offers exceptional performance for various applications, including building maintenance, tree care, and installations in challenging environments.

      Key Features and Benefits:

      • Double Pantograph Design: Features a double pantograph with articulated arms and jib, providing excellent performance without outreach-limiting devices.

      • Compact Dimensions: Allows access through standard doorways and operation in confined spaces.

      • Self Control System: Equipped with CMC's Self Control System for automatic control of stabilization, maneuvering speed, automatic closure of the aerial part, and collision prevention.

      • Versatile Power Options: Available with various engine configurations, including petrol, diesel, and electric, to suit different work environments.

      • Easy Transport: Lightweight design enables transportation on trailers or small vans.

      Specifications:

      • Maximum Working Height: 23 meters

      • Maximum Outreach: 12.4 meters

      • Platform Height: 21 meters

      • Basket Load Capacity: 200 kg

      • Basket Dimensions: 1.4 x 0.7 x 1.1 meters

      • Basket Rotation: ±90° (optional)

      • Turret Rotation: ±355° (710° continuous)

      • Total Weight: 3,000 kg
