Maintenance-free 3-year CO gas detector with Surecell technology, triple alarm system, and internal event logging. Ideal for hazardous environments with IP 66/67 protection and ATEX certification.
The BW Clip (3 Year) CO 20/100ppm is a maintenance-free single gas detector specifically designed for detecting carbon monoxide (CO) levels in hazardous environments. This disposable gas detector features a 3-year operational lifetime with no requirement for calibration, sensor replacement, battery replacement, or charging. The device is equipped with an LCD display that shows a countdown of the detector's remaining lifetime in months, allowing users to track when replacement is needed.
This portable gas detector utilizes advanced Surecell technology to ensure fast-responding sensors that perform reliably even under tough environmental conditions. The BW Clip operates continuously for up to 3 years once activated, with an automated self-test function that runs every 24 hours to ensure operational integrity. The detector features a comprehensive triple alarm system including visual, vibrating, and audible alarms (95 dB) with both low (20ppm) and high (100ppm) alarm levels. Internal event logging capability allows the device to record the most recent 35 events, which can be accessed and assessed using IntelliDox or MicroDock II systems.
With its lightweight design, one-button operation, and rugged concussion-proof housing with IP 66/67 ingress protection rating, the BW Clip is ideal for workers in hazardous industries including oil and gas, chemical processing, mining, and confined space entry operations. The detector comes with a stainless steel alligator clip for secure attachment to clothing or equipment, along with a test cap and comprehensive instructions. It is certified for use in Class I Division 1 and ATEX Zone 0 hazardous locations.
Key Features
- Maintenance-free operation for 3 years with no calibration or sensor replacement required
- Advanced Surecell technology for fast-responding and reliable performance under tough conditions
- Triple alarm system with visual, vibrating, and 95 dB audible alerts at low (20ppm) and high (100ppm) levels
- Internal event logging with capacity to record and assess the most recent 35 events
- Lightweight one-button operation with rugged concussion-proof housing and IP 66/67 ingress protection
- Automated 24-hour self-test function to ensure continuous operational integrity
- Compatible with IntelliDox and MicroDock II assessment systems
- ATEX and CUL certified for Class I Division 1 and Zone 0 hazardous locations
- Stainless steel alligator clip for secure attachment to clothing or equipment
- LCD display showing countdown of remaining detector lifetime in months
Technical Specifications
| Specification |
Value |
| Product Code | BWC3-M20100 |
| Measuring Range | 0-100 ppm |
| Low Alarm Level | 20 ppm |
| High Alarm Level | 100 ppm |
| Dimensions | 1.6 x 2.0 x 3.4 inches / 4.1 x 5.0 x 8.7 cm |
| Weight | 3.2 oz / 92 g |
| Operating Temperature Range | -22 to +122°F / -30 to +50°C |
| Operating Humidity Range | 5% - 95% RH (non-condensing) |
| Alarm System | Visual, Audible (95 dB), Vibrating - Low and High |
| Self-Test Function | Internal diagnostic test every 24 hours (activated detectors) |
| Battery Life | 3 years |
| Ingress Protection Rating | IP 66/67 |
| Gas Type | Carbon Monoxide (CO) |
| Detector Type | Disposable Single Gas Detector |
| Sensor Technology | Surecell |
| Event Logging Capacity | 35 most recent events |
| Certifications | CUL US, ATEX (CE Ex 0539 II 1G), IECEx, Class I Division 1 Group A B C D, Class I Zone 0 Group IIC |
| Warranty | 3 years from activation plus 1 year shelf life |
| Included Accessories | BW Clip with CO sensor, Stainless Steel Alligator Clip, Concussion-proof housing, Test Cap, Instructions |
| Compatible Systems | IntelliDox, MicroDock II |
Order BW Clip 3 Year CO 20/100ppm Portable Gas Detector at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
