All-in-one 2 gang multistandard power socket with integrated USB-A and USB-C charging ports, 16A rated, glossy white finish with tool-less installation for modern homes and offices.
The Belanko S 2 Gang Switched Multistandard Inboard USB (new) Type A+C White is a comprehensive all-in-one power solution designed for modern residential and commercial installations. This innovative socket combines two 2P+E multi-standard power outlets with integrated USB charging ports (USB-A and USB-C) in a single, elegant module. The product features marked terminals for easy identification, screw-type terminals for enhanced contact reliability, and a glossy white finish that complements contemporary interior designs. With a nominal current rating of 16A at 250V, this socket is suitable for 50-60 Hz frequency applications and provides 15W USB output power for efficient device charging.
Designed specifically for flush-mounted installation, the Belanko S multistandard socket offers tool-less installation capabilities and comes pre-packaged with protective shells against paint and dust during the installation phase. The device features enhanced contact protection and label space for terminal identification. It is optimized for both new builds and renovation projects, making it an ideal accessory for modern electrical installations. The product maintains an IP20 degree of protection and IK04 impact strength rating, ensuring durability in standard indoor environments. Operating temperature range is -5°C to 35°C, with storage temperature capabilities from -20°C to 70°C.
The Belanko S socket is constructed from halogen-free thermoplastic material, ensuring environmental compliance with RoHS and REACH directives. With dimensions of 146mm width × 86mm height × 30.5mm depth, and a built-in depth of 19.5mm, it requires a minimum installation box depth of 40mm. The product includes both plastic and metal box mounting screws for versatile installation options. This multi-functional outlet eliminates the need for multiple adapters and power strips, providing a streamlined, professional appearance while delivering comprehensive power management capabilities.
Key Features
- Two 2P+E multi-standard power outlets with 16A/250V rating
- Integrated USB-A and USB-C charging ports with 15W output power
- Tool-less installation with pre-included protective dust and paint shields
- Marked screw-type terminals for enhanced contact reliability and easy identification
- Halogen-free thermoplastic construction compliant with RoHS and REACH standards
- Glossy white finish with contemporary aesthetic design
- Enhanced contact protection with IP20 degree of protection rating
- IK04 impact strength rating for durability in standard indoor environments
- Flush-mounted installation with 19.5mm built-in depth
- Includes mounting screws for both plastic and metal installation boxes
Technical Specifications
| Specification |
Value |
| Product Model | Multi-standard Socket with USB Charging |
| Reference Number | 617655 |
| EAN Code | 3414971685154 |
| Number of Power Outlets | 2 x 2P+E Multi-standard |
| USB Ports | 1x USB-A + 1x USB-C |
| Nominal Current Rating | 16 A |
| Nominal Voltage | 250 V |
| Frequency Range | 50-60 Hz |
| USB Output Power | 15 W |
| Connection Type | Screw-type Terminals |
| Terminal Capacity | 1-4 mm² |
| Cable Support | Flexible or Rigid |
| Material | Halogen-free Thermoplastic |
| Surface Finish | Glossy |
| Color | White (RAL 9003) |
| Installation Method | Flush-mounted |
| Device Width | 146 mm |
| Device Height | 86 mm |
| Device Depth | 30.5 mm |
| Built-in Depth | 19.5 mm |
| Minimum Installation Box Depth | 40 mm |
| Degree of Protection | IP20 |
| Impact Strength Rating | IK04 |
| Operating Temperature Range | -5°C to +35°C |
| Storage Temperature Range | -20°C to +70°C |
| Number of Modules | 4 |
| Switchable Socket Outlets | 2 |
| Enhanced Contact Protection | Yes |
| Label Space Available | Yes |
| With On/Off Switch | Yes |
| Protective Shell Included | Yes |
| Mounting Screws Included | Yes (Plastic and Metal Box Types) |
| Compliance Standards | RoHS, REACH, British Standard |
| Recommended Use | Indoor Use Only |
| Application | Residential and Commercial Buildings |
