Premium 45W USB Type-C power delivery charger with advanced voltage regulation, featuring elegant magnesium design and universal device compatibility for modern homes and offices.
The Arteor USB charger is a modern, high-performance charging solution designed for contemporary homes and offices. This 2-module unit features a powerful 45W Type-C USB outlet with advanced Power Delivery technology, supporting multiple voltage outputs (5V, 9V, 12V, 15V, and 20V) to accommodate various devices including laptops, tablets, and smartphones. The device combines elegant magnesium construction with practical functionality, offering universal compatibility for rapid charging of modern portable devices.
This flush-mounted socket is engineered for seamless integration into standard 40mm installation boxes, making it ideal for both new installations and renovations. The screw terminal connection system ensures secure and reliable electrical connections, with support for cable sections ranging from 1.5mm² to 2.5mm². The charger operates on standard AC voltage (220-240V, 50-60Hz) and features intelligent power management with minimal standby consumption of just 0.074W, ensuring energy efficiency without compromising performance.
The Arteor USB charger is part of the prestigious Arteor collection by Legrand, known for its sophisticated design and premium quality. It provides maximum output current of 3000mA and includes terminal marking indicators for ease of installation. The device is halogen-free, environmentally conscious, and complies with IP40 protection rating and IK04 impact resistance standards, making it suitable for demanding residential and small commercial applications.
Key Features
- 45W USB Type-C Power Delivery with multi-voltage support (5V, 9V, 12V, 15V, 20V)
- Universal charger for laptops, tablets, and smartphones with Quick Charge capability
- Elegant magnesium construction with premium Arteor design aesthetic
- Secure screw terminal connections supporting 1.5-2.5mm² cable sections
- Low standby consumption of 0.074W for energy-efficient operation
- IP40 protection rating and IK04 impact resistance for durability
- Halogen-free and environmentally responsible design
- Compatible with standard 40mm flush-mounted installation boxes
- Maximum output current of 3000mA for rapid device charging
- Terminal marking indicators for simplified professional installation
Technical Specifications
| Specification |
Value |
| Product Type | USB Type-C Power Delivery Charger |
| Number of USB Ports | 1 x USB Type-C (45W) |
| Power Output | 45W with Power Delivery |
| Voltage Support | 5V, 9V, 12V, 15V, 20V |
| Input Voltage | 220-240V AC, 50-60Hz |
| Output Current (Maximum) | 3000mA |
| Output Voltage Range | 5-20V |
| Power Consumption | 0.074W (Standby) |
| Connection Type | Screw Terminals |
| Terminal Capacity | 1.5-2.5mm² |
| Cable Compatibility | Flexible or Rigid, 1.5-2.5mm² section |
| Mounting Method | Flush-mounted |
| Installation Box Depth | Minimum 40mm |
| Built-in Depth | 36.5mm |
| Device Dimensions | 45mm (width) x 45mm (height) x 45mm (depth) |
| Color | Magnesium/Aluminium |
| Number of Modules | 2 modules |
| Protection Rating (IP) | IP40 |
| Impact Resistance (IK) | IK04 |
| Operating Temperature | 5-40°C |
| Storage Temperature | -20-70°C |
| Voltage Type | AC (Alternating Current) |
| Wireless Capability | No |
| Antimicrobial Treatment | No |
| Halogen-Free | Yes |
| Neutral Conductor | Mandatory (Yes) |
| Terminal Marking | Yes (Terminal marking indication) |
| Number of Terminals | 2 |
| Supply Current | 0.8A |
| Reference Number | 575482 |
| EAN Code | 3414972505314 |
| Brand | Legrand |
| Collection | Arteor |
| Use Environment | Recommended for inside use only |
| Compatible Devices | Laptops, Tablets, Smartphones |
