Premium Arteor US socket outlet 15A/127V in champagne finish with halogen-free thermoplastic construction, NEMA 1-15 compliant, snap-mounted module design with screwed terminals and loop-through functionality.
The Arteor™ Socket US is a premium American-type electrical outlet designed for North American applications, featuring a 15A/127V capacity with 2-pole configuration. This single-module champagne-colored socket outlet is manufactured by Legrand and complies with NEMA 1-15 (Type A) standards. The device is constructed with high-quality thermoplastic material that is halogen-free, ensuring safety and environmental compliance. With its elegant titanium finish and matt surface protection, this socket outlet seamlessly integrates into modern interior designs while maintaining exceptional durability and reliability.
The Arteor US Socket features a robust snap-mounting system that allows for easy installation within standard module frames. The outlet is equipped with screwed terminals for secure cable connections, supporting flexible or rigid cables ranging from 2.5 to 2.5 mm² in cross-section. The device operates across a wide frequency range of 50-60 Hz and maintains operational stability across temperatures from -5°C to 50°C. With an IP20 protection rating and IK04 impact strength rating, this outlet is suitable for residential and light commercial applications, providing dependable power distribution with enhanced contact protection.
The socket outlet incorporates advanced safety features including loop-through functionality, allowing for convenient daisy-chaining of multiple outlets. The compact design with dimensions of 22.5mm width, 45mm height, and 38.1mm depth ensures space-efficient installation. Each unit comes with a reference number 571072 and EAN code 3414971851894, facilitating easy identification and inventory management. This Arteor socket outlet represents the perfect combination of functionality, aesthetics, and reliability for any modern electrical installation.
Key Features
- NEMA 1-15 Type A compliant American socket outlet rated for 15A at 127V
- Halogen-free thermoplastic material construction for enhanced safety and environmental compliance
- Elegant champagne-colored titanium finish with matt surface protection
- Snap-mounting system for easy installation in standard module frames
- Loop-through functionality for convenient daisy-chaining of multiple outlets
- Screwed terminals supporting flexible or rigid cables 2.5-2.5mm² cross-section
- Wide operating frequency range of 50-60 Hz with temperature stability -5°C to 50°C
- IP20 protection rating and IK04 impact strength for residential and light commercial use
- Compact dimensions: 22.5mm width, 45mm height, 38.1mm depth
- Single-module design with built-in depth of 26.7mm for space-efficient installation
Technical Specifications
| Specification |
Value |
| Product Type | American Type Socket Outlet |
| Model Standard | NEMA 1-15 (Type A) / US/CA/CN |
| Nominal Current | 15 Amperes |
| Nominal Voltage | 127 Volts AC |
| Frequency Range | 50-60 Hz |
| Number of Poles | 2 Poles |
| Number of Modules | 1 Module |
| Number of Socket Outlets | 1 |
| Contact Configuration | 2 Flat Active Contacts |
| Connection Type | Screwed Terminal |
| Cable Support | Flexible or Rigid |
| Cable Section Range | 2.5-2.5 mm² |
| Material | Thermoplastic - Halogen Free |
| Color | Champagne/Titanium |
| Surface Finish | Lacquered Matt |
| Mounting Method | Module Frame Snap Mounting |
| Type of Fastening | Snap Mounting (Engagement) |
| Device Width | 22.5 mm |
| Device Height | 45 mm |
| Device Depth | 38.1 mm |
| Built-in Depth | 26.7 mm |
| Protection Rating (IP) | IP20 |
| Impact Strength Rating (IK) | IK04 |
| Operating Temperature Range | -5°C to +50°C |
| Storage Temperature Range | -10°C to +70°C |
| Assembly Arrangement | Basic Element with Central Cover Plate |
| Protective Contact | None |
| Concurrently Switching Neutral | No |
| Luminous Signal | No |
| USB Ports | None (USB-A: 0, USB-C: 0) |
| Switchable Socket Outlets | 0 |
| Enhanced Contact Protection | No |
| Hinged Lid | No |
| Label Space | No |
| Lockable | No |
| Eject Mechanism | No |
| Insulated Mounting | No |
| Function Lighting | No |
| Overvoltage Protection | No |
| Fault Current Protection | No |
| Miniature Fuse | No |
| Loop Through Function | Yes |
| On/Off Switch | No |
| Voltage Type | AC (Alternating Current) |
| Power Delivery | No |
| Connected Object | No |
| Apple HomeKit Compatible | No |
| Amazon Alexa Compatible | No |
| Google Assistant Compatible | No |
| IFTTT Support | No |
| Wi-Fi Signal Repeater | No |
| Built-in Bluetooth Speaker | No |
| Heavy Conditions VDE Rating | No |
| Reference Number | 571072 |
| EAN Code | 3414971851894 |
| Brand | Legrand |
| Product Line | Arteor™ (International) |
