Shop Legrand Arteor Socket US 15A 127V 2P 1 Module Soft Alu | 570072 In Iraq Best Prices
Premium American-standard socket outlet with 15A/127V rating, NEMA 1-15 Type A configuration, soft aluminum finish, and halogen-free thermoplastic construction for reliable residential and commercial electrical connections.
The Arteor Socket US is a premium American-standard electrical outlet designed for North American applications including the US, Canada, and China markets. This NEMA 1-15 Type A socket outlet features a 15A/127V rating with 2 flat active contacts arranged in a 1-module configuration. The socket is finished in elegant Soft Aluminum, providing a modern aesthetic that complements contemporary interior designs. Manufactured by Legrand, a global leader in electrical and digital infrastructure, this outlet combines reliability with sophisticated styling. The mechanism comes supplied with rocker plates and requires support frames and decorative plates for complete installation, making it ideal for residential and commercial applications requiring standardized North American electrical connections.
This socket outlet is constructed from high-quality thermoplastic material that is halogen-free, meeting modern environmental and safety standards. The device features a compact design with dimensions of 22.5mm width, 45mm height, and 38.1mm depth, with a built-in depth of 26.7mm for seamless integration into standard electrical boxes. The outlet operates across 50-60Hz frequency ranges and maintains performance in operating temperatures from -5°C to 50°C, with storage capability from -10°C to 70°C. With IP20 degree of protection and IK04 impact strength rating, this outlet is suitable for general indoor environments and provides reliable daily-use performance.
The Arteor Socket features screwed terminal connections accommodating flexible or rigid cables with a cross-section of 2.5mm², ensuring secure and durable electrical connections. The loop-through function allows for convenient daisy-chaining of multiple outlets in series, simplifying installation in complex wiring scenarios. As part of the Arteor international range, this outlet maintains consistency with other Legrand products, facilitating uniform design throughout residential and commercial spaces. The product meets rigorous compliance standards including RoHS directive requirements, demonstrating Legrand's commitment to safety, quality, and environmental responsibility.
Key Features
- NEMA 1-15 Type A American standard socket outlet rated for 15A/127V
- Halogen-free thermoplastic construction meeting modern environmental standards
- Elegant Soft Aluminum finish complementing contemporary interior designs
- Compact 1-module design with loop-through function for daisy-chaining multiple outlets
- Screwed terminal connections accommodating 2.5mm² flexible or rigid cables
- IP20 protection rating and IK04 impact strength suitable for general indoor use
- Operating temperature range -5°C to 50°C with storage capability -10°C to 70°C
- RoHS directive compliant ensuring safety and environmental responsibility
- Requires support frames and decorative plates for complete installation
- Compatible with 50-60Hz frequency for universal North American applications
Technical Specifications
| Specification |
Value |
| Product Type | American Standard Socket Outlet |
| Socket Standard | NEMA 1-15 Type A (US/CA/CN) |
| Rated Current | 15 Amperes |
| Rated Voltage | 127 Volts AC |
| Number of Poles | 2 Poles |
| Number of Modules | 1 Module |
| Active Contacts | 2 Flat Contacts |
| Finish Color | Soft Aluminum |
| Material | Halogen-Free Thermoplastic |
| Surface Protection | Untreated |
| Surface Finishing | Glossy |
| Connection Type | Screwed Terminal |
| Cable Section Range | 2.5-2.5 mm² |
| Cable Type | Flexible or Rigid |
| Device Width | 22.5 mm |
| Device Height | 45 mm |
| Device Depth | 38.1 mm |
| Built-in Depth | 26.7 mm |
| Protection Degree (IP) | IP20 |
| Impact Strength (IK) | IK04 |
| Operating Temperature Range | -5°C to +50°C |
| Storage Temperature Range | -10°C to +70°C |
| Frequency Range | 50-60 Hz |
| Mounting Method | Module Frame Snap Mounting |
| Loop Through Function | Yes |
| Hinged Lid | No |
| Enhanced Contact Protection | No |
| Overvoltage Protection | No |
| Fault Current Protection | No |
| Halogen Free | Yes |
| RoHS Compliant | Yes |
| Reference Number | 570072 |
| EAN Code | 3414971851498 |
| Manufacturer | Legrand |
| Product Range | Arteor International |
