Shop Legrand Arteor Euro-US Socket Outlet 16A 250V Magnesium | 572604 In Iraq Best Prices
Premium multi-standard Euro-US socket outlet with enhanced safety shutters, 16A/250V rated, halogen-free thermoplastic construction in elegant magnesium finish for residential and commercial applications.
The Arteor™ Socket - Euro-US is a versatile multi-standard socket outlet designed for international compatibility. This premium wiring device combines European and US socket standards in a single, elegant unit, making it ideal for modern homes and commercial spaces that require flexibility in power connectivity. The socket features enhanced contact protection with shutters and is manufactured from high-quality thermoplastic material in a sophisticated magnesium finish.
This 1-module socket outlet delivers reliable performance with a nominal current rating of 16A at 250V, operating across standard 50-60Hz frequencies. The device is equipped with advanced safety features including protective shutters that prevent accidental contact with live parts. The screwed terminal connection type ensures secure and stable electrical connections, while the snap-mounting system allows for quick and easy installation within standard module frames.
The Arteor™ socket is halogen-free and environmentally compliant, meeting modern sustainability standards. With its IP40 degree of protection and IK04 impact strength rating, this outlet is suitable for both residential and commercial applications. The device supports flexible or rigid cable connections with a cable section range of 2.5-2.5 mm², making it compatible with standard electrical installations. Its compact dimensions (22.5mm width, 45mm height, 35.1mm depth) ensure seamless integration into existing wall installations.
Key Features
- Multi-standard Euro-US socket compatibility for international power connectivity
- Enhanced contact protection with safety shutters preventing accidental contact
- Halogen-free thermoplastic material meeting environmental sustainability standards
- Snap-mounting system for quick and easy installation in standard module frames
- IP40 degree of protection and IK04 impact strength rating for reliable durability
Technical Specifications
| Specification |
Value |
| Product Type | Multi-standard Socket Outlet |
| Socket Standard | Euro-US Type |
| Nominal Current | 16A |
| Nominal Voltage | 250V |
| Frequency Range | 50-60 Hz |
| Number of Modules | 1 module |
| Number of Socket Outlets | 1 |
| Active Contacts (Round) | 2 |
| Active Contacts (Flat) | 2 |
| Contact Protection | Enhanced with Shutters |
| Connection Type | Screwed Terminal |
| Cable Section Range | 2.5-2.5 mm² |
| Material | Thermoplastic |
| Material Quality | High-grade Thermoplastic |
| Halogen Free | Yes |
| Surface Finish | Matt Lacquered |
| Colour | Magnesium Grey |
| Device Width | 22.5 mm |
| Device Height | 45 mm |
| Device Depth | 35.1 mm |
| Built-in Depth | 27.8 mm |
| Degree of Protection | IP40 |
| Impact Strength Rating | IK04 |
| Mounting Method | Module Frame with Snap Mounting |
| Operating Temperature Range | -5°C to +50°C |
| Storage Temperature Range | -10°C to +70°C |
| Voltage Type | AC |
| Assembly Arrangement | Basic Element with Central Cover Plate |
| With Loop Through Function | Yes |
| Switching Neutral Conductor | No |
