Shop Legrand Arteor BS Wired Light Switch 1-Gang Without Neutral White | 574617 In Iraq Best Prices
Smart connected light switch with Zigbee 3.0 technology, voice control compatibility, 600W capacity, and elegant white design for modern smart homes
The Arteor™ BS wired light switch 1 gang without neutral in white is a premium connected lighting control solution from Legrand that combines elegant design with advanced smart home technology. This innovative switch features Zigbee 3.0 protocol connectivity, allowing seamless voice control through Google Assistant, Amazon Alexa, and Apple Siri. With a maximum load capacity of 600W under 230VAC, this relay-type switch is compatible with traditional bulbs, dimmable loads, and LED retrofits, making it versatile for any lighting application.
The switch is equipped with an LED indicator with locator function that can be activated via the Home + Control app, providing convenient visibility in low-light conditions. Installation is straightforward, requiring only a standard 25mm depth flush mounting box, and the switch does not require a neutral wire connection, simplifying installation in existing electrical systems. The bleeder is supplied with the product to ensure optimal performance with LED loads and dimmable bulbs.
Designed with multi-zone ergonomics and perfect aesthetic integration with Legrand's Arteor wiring device range, this switch offers ON/OFF mode functionality compatible with all load types. The product supports programmable scheduling through smartphone apps and features IP20 protection rating with IK04 impact strength. With standby consumption of only 0.1 mA, this energy-efficient solution is ideal for modern smart home installations, supporting interoperable connections and Internet box connectivity.
Key Features
- Zigbee 3.0 protocol for reliable and secure wireless connectivity
- Compatible with Google Assistant, Amazon Alexa, and Apple Siri voice control
- 600W maximum load capacity supporting traditional, dimmable, and LED bulbs
- LED indicator with locator function activated via Home + Control app
- Installation without neutral wire requirement in standard 25mm flush mounting boxes
- Energy-efficient with only 0.1 mA standby consumption
- Programmable scheduling through smartphone applications
- Multi-zone ergonomic design with perfect aesthetic integration
- IP20 protection rating and IK04 impact strength
- Supplied with bleeder for optimal LED and dimmable load performance
Technical Specifications
| Specification |
Value |
| Product Reference | 574617 |
| EAN Code | 3414972219525 |
| Brand | Legrand |
| Product Line | Arteor™ BS |
| Type | Wired Light Switch - 1 Gang Relay |
| Color | White (RAL 9003) |
| Nominal Voltage | 230V AC |
| Frequency | 50-60 Hz |
| Rated Current | 2.6 A |
| Maximum Load Power | 600W under 230VAC (all loads including LEDs) |
| Switch Capacity Range | 0-600W |
| Number of Channels | 1 |
| Material | Thermoplastic |
| Surface Finishing | Glossy |
| Mounting Method | Flush-mounted |
| Minimum Depth of Built-in Installation Box | 25 mm |
| Built-in Depth | 22.5 mm |
| Width | 81.5 mm |
| Height | 81.5 mm |
| Depth | 33 mm |
| Degree of Protection (IP) | IP20 |
| Degree of Impact Strength (IK) | IK04 |
| Operating Temperature Range | 5-45°C |
| Storage Temperature Range | 0-45°C |
| Standby Consumption | 0.1 mA |
| Connection Type | Screwed Terminal |
| Number of Terminals | 2 |
| Terminal Capacity | 1.5-4 mm² |
| Cable Section | 1.5-4 mm² |
| Mandatory Neutral | No |
| Terminal Marking Indication | Yes |
| Halogen Free | Yes |
| Type of Fastening | Mounting with Screw |
| Wireless Protocol | Zigbee 3.0 (2.4GHz) |
| Compatible Voice Assistants | Google Assistant, Amazon Alexa, Apple Siri |
| Compatible with Apple HomeKit | Yes |
| Compatible with Google Assistant | Yes |
| Compatible with Amazon Alexa | Yes |
| IFTTT Support | No |
| Application Name | Home + Control |
| Application Store | App Store, Google Play Store |
| Programmable | Yes |
| Programming Method | Smartphone Apps |
| Interoperable Connection Protocol | Yes |
| Connectable by Internet Box | Yes |
| Product Use Function | Lighting Management |
| LED Indicator | Yes, with Locator Function |
| Auxiliary Entry | Yes, for mechanical push buttons without lamp |
| Load Type Compatibility | Universal and LED Retrofit |
| Applicable with Transmission Button | Yes |
| Applicable with Movement Sensor | Yes |
| Applicable with Time Switch/Timer | Yes |
| Light Value Memory | No |
| Bleeder Included | Yes |
| Contains Batteries or Accumulator | No |
| Connected Object | Yes |
| With Voice Command | Yes |
| Operating Method | Zigbee |
| Stress Test Conformity (1000V) | No |
| Antimicrobial Treatment | No |
