Shop Legrand Arteor BS Wired Dimmer 300W 1-Gang Without Neutral Champagne | 574640 In Iraq Best Prices
Premium connected dimmer switch with 300W capacity, no neutral required, voice control compatibility, and elegant champagne finish for modern smart homes
The Arteor BS wired dimmer 300W 1 gang without neutral in champagne finish is a sophisticated connected lighting control solution designed for modern homes and commercial spaces. This premium dimmer switch combines elegant aesthetics with advanced smart home functionality, allowing users to seamlessly control their lighting through voice commands via Google Assistant, Amazon Alexa, or Apple Siri. The device features a maximum load power of 200W under 230V~, making it compatible with all types of dimmable bulbs, including LED bulbs with bleeder technology, ensuring smooth and flicker-free dimming performance.
Installation is remarkably simple and requires no neutral wire connection, making it an ideal retrofit solution for existing installations. The dimmer fits into standard depth flush mounting boxes (25mm) and features intuitive multi-zone ergonomics for easy operation. With its integrated LED indicator and locator function activated through the Home + Control App, users can effortlessly manage their lighting ambiance. The device is equipped with an auxiliary entry for mechanical push buttons and wireless light switches, providing flexible control options for any room configuration.
Powered by 2.4GHz radio technology utilizing the secure Zigbee 3.0 protocol, this connected dimmer offers reliable and stable operation. The champagne finish provides perfect aesthetic integration with installed wiring devices, while the planar geometry and premium plastic surface treatment ensure easy maintenance and cleaning. Compatible with both ON/OFF mode and universal LED Retrofit loads, the Arteor BS dimmer represents the pinnacle of connected home lighting control technology.
Key Features
- 300W maximum load power with universal and LED Retrofit compatibility
- No neutral wire required for installation, ideal for retrofit applications
- Voice control via Google Assistant, Amazon Alexa, and Apple Siri
- 2.4GHz Zigbee 3.0 protocol for secure and reliable wireless connectivity
- LED indicator with locator function controllable through Home + Control App
- Auxiliary entry for mechanical push buttons and wireless light switches
- Elegant champagne finish with planar geometry for easy cleaning
- Light value memory function for convenient dimming preferences
- Compatible with dimmable bulbs including LED with bleeder technology
- Programmable through smartphone apps for flexible automation
Technical Specifications
| Specification |
Value |
| Product Reference | 574640 |
| EAN Code | 3414972219303 |
| Brand | LEGRAND |
| Series | Arteor™ |
| Model | Tronic |
| Nominal Voltage | 230V |
| Frequency | 50-60 Hz |
| Rated Current | 1.3 A |
| Max Load Power | 200W under 230V~, all loads including LEDs with bleeder |
| Switch Capacity | 5-300 W |
| Number of Channels | 1 |
| Type of Load | Universal and LED Retrofit |
| Mounting Method | Flush-mounted |
| Minimum Depth of Built-in Box | 25 mm |
| Built-in Depth | 22.5 mm |
| Width | 81.8 mm |
| Height | 81.5 mm |
| Total Depth | 33 mm |
| Material | Thermoplastic |
| Surface Protection | Lacquered |
| Surface Finishing | Matt |
| Colour | Titanium/Champagne |
| Degree of Impact Strength | IK04 |
| Degree of Protection | IP20 |
| Operating Temperature Range | 5-45 °C |
| Storage Temperature Range | 0-45 °C |
| Standby Consumption | 0.3 mA |
| Neutral Wire Required | No |
| Connection Type | Screwed terminal |
| Number of Terminals | 2 |
| Terminal Capacity | 1.5-4 mm² |
| Cable Section | 1.5-4 mm² |
| Radio Technology | 2.4GHz Zigbee 3.0 |
| Operating Method | Zigbee |
| Connected Object | Yes |
| Programmable | Yes |
| Voice Command Support | Yes |
| Compatible Voice Assistants | Google Assistant, Amazon Alexa, Apple Siri |
| Apple HomeKit Compatible | Yes |
| Google Assistant Compatible | Yes |
| Amazon Alexa Compatible | Yes |
| Application Name | Home + Control |
| Application Store | App Store, Google Play Store |
| Product Use Function | Lighting management |
| Interoperable Connection Protocol | Yes |
| Connectable by Internet Box | Yes |
| Halogen Free | Yes |
| Contains Batteries | No |
| Substation Input | Yes |
| Light Value Memory | Yes |
| Applicable with Movement Sensor | Yes |
| Applicable with Time Switch/Timer | Yes |
| Applicable with Transmission Button | Yes |
| Assembly Arrangement | Basic element with central cover plate |
