Shop Legrand Arteor British Standard 2P+E Switched Socket Outlet 15A Champagne | 570045 In Iraq Best Prices
Premium British standard 2P+E switched socket outlet with child safety shutters, 15A capacity, and champagne finish. ASTA certified, halogen-free construction, IP40 rated protection.
The Arteor™ British standard 2P+E switched socket outlet 15A is a premium electrical wiring device designed for modern residential and commercial applications. This 3-module socket outlet features advanced child safety shutters and conforms to BS 1363 Part 2 standards, ensuring maximum protection and reliability. The champagne-colored finish provides an elegant aesthetic that complements contemporary interior designs while maintaining professional-grade performance.
This switched socket outlet is equipped with enhanced contact protection and features a robust thermoplastic construction with halogen-free materials, making it environmentally responsible and safe for use in various settings. The device operates at 250V AC with a nominal current of 16A and maintains stable performance across 50-60 Hz frequencies. With its snap-mounting system and screwed terminal connections, installation is straightforward and secure, supporting flexible or rigid cables with a 4-4 mm² cross-section.
The Arteor™ socket outlet includes a full cover plate assembly and comes with a hinged rocker plate for convenient on/off switching. It features loop-through functionality, allowing for flexible installation configurations in multi-outlet scenarios. The device maintains operational stability across temperatures from -5°C to 50°C and offers IP40 protection rating with IK04 impact strength, making it suitable for standard indoor environments. ASTA licensed and manufactured to the highest standards, this socket outlet represents the perfect blend of safety, functionality, and design excellence.
Key Features
- British Standard BS 1363 Part 2 compliant with ASTA license certification
- Child safety shuttered design for enhanced protection and peace of mind
- On/off switch with titanium-colored rocker plate for convenient control
- Halogen-free thermoplastic construction for environmental responsibility
- Loop-through functionality enabling flexible multi-outlet installation configurations
- Enhanced contact protection with screwed terminal connections
- IP40 protection rating with IK04 impact strength for standard indoor use
- Supports flexible or rigid cables with 4-4 mm² cross-section capacity
Technical Specifications
| Specification |
Value |
| Product Type | 2P+E Switched Socket Outlet |
| Standard Compliance | British Standard BS 1363 Part 2, BS 546 |
| Nominal Current | 16A (15A outlet rating) |
| Nominal Voltage | 250V AC |
| Frequency Range | 50-60 Hz |
| Number of Modules | 3 modules |
| Number of Socket Outlets | 1 outlet |
| Connection Type | Screwed Terminal |
| Cable Section | 4-4 mm² (flexible or rigid) |
| Material | Halogen-free Thermoplastic |
| Colour | Champagne/Titanium |
| Protection Rating | IP40 |
| Impact Strength | IK04 |
| Device Dimensions | 41.5 x 45 x 41.5 mm |
| Built-in Depth | 28.5 mm |
| Operating Temperature Range | -5°C to 50°C |
| Storage Temperature Range | -10°C to 70°C |
| Mounting Method | Module Frame with Snap Mounting |
| Contact Type | Round protective contact (2P+E) |
| Switch Operator | Titanium-colored rocker plate |
| Child Safety | Shuttered design for enhanced protection |
| Loop-Through Function | Yes |
| Enhanced Contact Protection | Yes |
| Certification | ASTA licensed |
| Reference Number | 570045 |
| EAN Code | 3414970924193 |
