Premium modular 1-way double pole switch with LED indicator, 20A 250V rating, soft aluminum finish, and advanced safety features for modern electrical installations.
The Arteor 1-way double pole switch is a premium modular switching device designed for residential and commercial electrical installations. This sophisticated switch features a red LED indicator light that illuminates when the switch is in the ON position, providing visual confirmation of the circuit status. With a rated capacity of 20A at 250V~, it is suitable for controlling various electrical loads including lighting circuits and general-purpose outlets. The switch operates on a reliable rocker/button mechanism and is housed in an elegant soft aluminum finish that complements modern interior designs.
This modular device occupies 2 modules within the standard domestic switching device frame system, making it an ideal solution for space-conscious installations. The switch incorporates advanced thermoplastic construction with halogen-free materials, ensuring safety and environmental compliance. The LED indicator is exchangeable, allowing for easy maintenance and replacement when needed. The device is engineered to withstand an impact strength rating of IK04 and operates reliably across a wide temperature range from -5°C to 50°C, making it suitable for diverse climate conditions.
The Arteor switch utilizes a secure screw terminal connection system that accommodates cable sections from 6 to 6 mm², ensuring safe and reliable electrical connections. It is fully compatible with both 50Hz and 60Hz frequency standards, making it universally applicable across different regions. The round design with soft aluminum finish provides an aesthetically pleasing appearance while maintaining functional excellence in any modern electrical installation.
Key Features
- Red LED indicator light illuminates in ON position for visual circuit status confirmation
- Double pole switching mechanism for enhanced electrical control and safety
- Modular design occupying 2 modules compatible with standard domestic switching frames
- Halogen-free thermoplastic construction ensuring environmental safety and compliance
- Exchangeable LED indicator for easy maintenance and long-term reliability
- Soft aluminum finish providing modern aesthetic appeal
- IK04 impact strength rating for durability in high-traffic areas
- Universal frequency compatibility with 50Hz and 60Hz standards
- Secure screw terminal connections for reliable electrical bonding
- Wide operating temperature range from -5°C to 50°C
Technical Specifications
| Specification |
Value |
| Product Type | 1-Way Double Pole Switch with Indicator |
| Brand | Legrand Arteor |
| SKU/Reference | 573148 |
| EAN Code | 3414971850002 |
| Nominal Voltage | 250V AC |
| Rated Current | 20A |
| Switching Current for Fluorescent Lamps | 20 AX |
| Number of Modules | 2 modules |
| Wiring System | 2-pole switch |
| Method of Operation | Rocker/Button |
| Number of Rockers | 1 |
| Mounting Method | Module Frame (Modular device for domestic switching) |
| Type of Fastening | Engage (Snap) |
| Material | Thermoplastic (Halogen-free) |
| Color | Soft Aluminum |
| Surface Finishing | Matt |
| Lighting Feature | Yes - LED Illuminated (ON) |
| LED Type | Red LED - Exchangeable |
| Device Width | 45 mm |
| Device Height | 45 mm |
| Device Depth | 42.2 mm |
| Built-in Depth | 28.5 mm |
| Minimum Built-in Installation Box Depth | 30 mm |
| Degree of Protection (IP) | IP40 |
| Impact Strength Rating (IK) | IK04 |
| Connection Type | Screwed Terminal |
| Cable Section Range | 6-6 mm² |
| Operating Temperature Range | -5°C to +50°C |
| Storage Temperature Range | -10°C to +70°C |
| Voltage Type | AC (Alternating Current) |
| Frequency Compatibility | 50-60 Hz |
| Push Button Switch | No |
| Monitoring Contact | No |
| Heating Switch | No |
| Washing Machine Switch | No |
| Smart Home Compatibility | Not compatible with Apple HomeKit, Google Assistant, or Amazon Alexa |
| Antimicrobial Treatment | No |
| Label Space/Information Surface | No |
| Warranty | Standard manufacturer warranty applies |
