Shop Legrand Art d'Arnould USB Charger 3A 15W Brushed Steel Socket | AR-68226 In Iraq Best Prices
Premium dual British Standard socket with integrated USB-A and USB-C charging ports delivering 15W power. Features brushed steel finish, screw terminals, and reliable 10,000+ insertion testing.
The Art d'Arnould A+A USB charger 3A 15W in brushed steel finish is a premium dual-function electrical socket combining traditional British Standard 2-gang switched socket outlet with integrated USB charging capability. This sophisticated wiring device features both USB-A and USB-C ports, delivering 15W of power output to simultaneously charge multiple devices including smartphones, tablets, and power banks. The product is manufactured with high-quality brass materials and comes pre-delivered with a 2-gang decorative plate in brushed brass finish (86x146mm), ensuring seamless integration into any modern interior design.
Designed for reliability and safety, this socket outlet meets CEI 62368-1:2014 Safety standards and BS1363 specifications. The unit features screw-type terminals with capacity for 2.5mm² to 6mm² cables, compatible with both flexible and rigid wiring installations. The brushed gold metallic finish provides an elegant aesthetic while maintaining durability for long-term use. The socket has been tested for mechanical reliability up to 10,000 USB insertions, certified by Legrand laboratories, ensuring consistent performance over extended periods.
This flush-mounted installation socket is ideal for residential and light commercial applications where modern charging solutions are required alongside traditional power outlets. The eject mechanism for USB ports, enhanced contact protection, and lockable design provide user convenience and safety. Perfect for contemporary homes, offices, and hospitality settings, the Art d'Arnould USB charger combines functionality with elegant design, making it an essential upgrade for any modern electrical installation.
Key Features
- Dual 2-gang British Standard switched socket outlet 13A 250V with integrated USB charging
- USB-A and USB-C ports with 3A 15W power delivery for simultaneous multi-device charging
- Brushed gold metallic finish with premium brass decorative plate (86x146mm)
- Certified mechanical reliability with 10,000+ USB insertion test cycles
- Screw terminals compatible with 2.5mm² to 6mm² flexible or rigid cables
- Enhanced contact protection with eject mechanism and lockable design
- CEI 62368-1:2014 Safety and BS1363 compliant
- Indoor flush-mounted installation for residential and commercial applications
- Prewired USB socket with 24mm built-in depth for standard mounting boxes
Technical Specifications
| Specification |
Value |
| Product Model | British Standard 2-gang switched socket + USB A+C |
| Socket Configuration | 2 gang BS socket outlet 13A 250V single pole switched + USB A+C 3A 5V 15W |
| USB Ports | 1x USB-A port, 1x USB-C port |
| Power Output | 15W at 5V DC |
| Nominal Current | 13A |
| Nominal Voltage | 250V AC |
| Frequency | 50-60 Hz |
| Color Finish | Brushed gold metallic |
| Material | Brass with metallic surface protection |
| Plate Dimensions | 86mm (H) x 146mm (W) |
| Device Depth | 33mm (overall), 24mm (built-in) |
| Minimum Installation Box Depth | 40mm |
| Terminal Type | Screw terminals |
| Terminal Capacity | 2.5mm² to 6mm² (2x 2.5mm², 2x 4mm², 2x 6mm²) |
| Cable Stripping Length | 12mm |
| Cable Compatibility | Flexible or rigid cables |
| Protection Degree (IP) | IP20 |
| Impact Strength (IK) | IK02 |
| Operating Temperature | -5°C to +35°C |
| Storage Temperature | -10°C to +70°C |
| Installation Method | Flush-mounted with screw fastening |
| Mounting Type | Basic element with full cover plate |
| Number of Modules | 4 modules |
| Switching Function | Single pole switched on both sockets |
| Enhanced Contact Protection | Yes |
| Eject Mechanism | Yes |
| Lockable Design | Yes |
| Mechanical Testing | 10,000+ USB insertion cycles certified |
| Safety Standards | CEI 62368-1:2014, BS1363 |
| Halogen Free | Yes |
| Reference Number | AR-68226 |
| EAN Code | 3233625159496 |
| Manufacturer | Legrand |
| Range | Art d'Arnould |
| Installation Location | Indoor use only |
| Voltage Type | AC |
| Power Delivery Support | No |
| Concurrent Neutral Switching | No |
| Protective Contact | Flat |
| Connection Type | Screwed terminal |
| With Hinged Lid | No |
| Function Lighting | No |
| Orientation Lighting | No |
| Overvoltage Protection | No |
| Fault Current Protection | No |
| Miniature Fuse | No |
| Smart Home Compatibility | Not compatible with Apple HomeKit, Amazon Alexa, or Google Assistant |
Order Legrand Art d'Arnould USB Charger 3A 15W Brushed Steel Socket | AR-68226 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
