Description

Compact relay with 12V DC control, SPDT output, and LED indicator.
The CR-M012DC4 pluggable interface relay is a compact and efficient relay designed for seamless integration into ABB CR-M sockets. This miniature relay operates with a 12 V DC rated control supply voltage and features a 4 c/o (SPDT) output with contacts rated at 250 V / 6A. This provides the capability to switch multiple circuits with a single input signal. Enhanced with an integrated test button, the relay allows manual actuation by locking its output contacts, facilitating easy testing and commissioning. Additionally, the relay includes an LED for visual indication of the relay coil's energization. Accessories such as standard sockets, logic sockets, pluggable function modules, holders, and markers are available to enhance functionality and ease of use.

Key Features

  • 12 V DC rated control supply voltage
  • 4 c/o (SPDT) output rated at 250 V / 6A
  • Integrated test button for manual actuation
  • LED indication for coil energization
  • Compatible with various pluggable function modules

Technical Specifications

Specification Value
MaterialHigh-quality plastic
Dimensions27.5 x 35.6 x 21.2 mm
Weight0.033 kg
Power12 V DC control voltage
Warranty2 years

Read more

Product form

ABB CR-M012DC4 Interface Relay

ABB

ريليه صغير مع تحكم 12 فولت تيار مستمر، مخرج SPDT، ومؤشر LED. Read more

    SKU: 1SVR405613R4000

          ريليه صغير مع تحكم 12 فولت تيار مستمر، مخرج SPDT، ومؤشر LED.

          Description

          Compact relay with 12V DC control, SPDT output, and LED indicator.
          The CR-M012DC4 pluggable interface relay is a compact and efficient relay designed for seamless integration into ABB CR-M sockets. This miniature relay operates with a 12 V DC rated control supply voltage and features a 4 c/o (SPDT) output with contacts rated at 250 V / 6A. This provides the capability to switch multiple circuits with a single input signal. Enhanced with an integrated test button, the relay allows manual actuation by locking its output contacts, facilitating easy testing and commissioning. Additionally, the relay includes an LED for visual indication of the relay coil's energization. Accessories such as standard sockets, logic sockets, pluggable function modules, holders, and markers are available to enhance functionality and ease of use.

          Key Features

          • 12 V DC rated control supply voltage
          • 4 c/o (SPDT) output rated at 250 V / 6A
          • Integrated test button for manual actuation
          • LED indication for coil energization
          • Compatible with various pluggable function modules

          Technical Specifications

          Specification Value
          MaterialHigh-quality plastic
          Dimensions27.5 x 35.6 x 21.2 mm
          Weight0.033 kg
          Power12 V DC control voltage
          Warranty2 years

          Read more
