Shop Snap-On 9/16" 12-Point SAE Flank Drive® Short Combination Wrench | OEX180B In Iraq Best Prices
Professional 9/16" short-handle combination wrench with Flank Drive® 12-point system delivering 15-20% more turning power, ideal for tight spaces and restricted clearance work.
The 9/16" 12-Point SAE Flank Drive® Short Combination Wrench (Model OEX180B) is a professional-grade tool engineered for demanding maintenance and repair applications. This short-handle wrench is specifically designed to provide superior access in tight spaces where standard-length wrenches cannot reach. The innovative Flank Drive® system grips the fastener flats with exceptional precision, delivering up to 15-20% more turning power compared to conventional wrenches, reducing the risk of fastener damage and rounding.
Crafted from special alloy steel that is precision forged and heat treated, this wrench combines exceptional strength with durability to withstand rigorous industrial use. The 7.5° offset broaching feature allows users to flip the box end over to obtain more advantageous grip positions in restricted clearance areas, maximizing versatility in confined workspaces. The continuous arc design distributes stress evenly across the entire wrench opening radius, providing superior strength and extended tool life.
Finished with tough, durable nickel-chrome plating that produces a mirror-like appearance, this wrench resists corrosion and remains easy to clean and maintain. The tool is sized for optimum comfort and balance, reducing user fatigue during extended use. Compliant with ASME® B107.100 standards, this 12-point short combination wrench is an essential addition to any professional mechanic's toolkit, particularly for aviation, aerospace, military, defense, oil and gas, and general industrial applications.
Key Features
- Short-handle design for superior access in tight spaces and confined work areas
- Flank Drive® system provides up to 15-20% more turning power than conventional wrenches
- 7.5° offset broaching allows flipping for advantageous grip in restricted clearance areas
- Continuous arc design distributes stress across entire wrench opening for greater strength
- Precision forged special alloy steel with heat treatment for superior strength and durability
- Nickel-chrome plating with mirror-like finish resists corrosion and simplifies cleaning
- 12-point configuration for versatile fastener engagement
- Sized for optimal comfort and balance during extended use
- ASME® B107.100 compliant for professional standards
- Ideal for aviation, aerospace, military, defense, and industrial applications
Technical Specifications
| Specification |
Value |
| Model Number | OEX180B |
| Size | 9/16 inches |
| Style | 12-Point |
| Type | SAE Flank Drive® Short Combination Wrench |
| Length | 6-1/16 inches |
| Dimension A (Outside Diameter) | 27/32 inches |
| Dimension B (Outside Diameter) | 1-5/32 inches |
| Dimension C (Head Depth) | 3/8 inches |
| Dimension D (Head Depth) | 9/32 inches |
| Finish | Nickel-Chrome Plating |
| Material | Special Alloy Steel, Precision Forged and Heat Treated |
| Offset | 7.5° offset broaching |
| Standards Compliance | ASME® B107.100 |
| Design Feature | Continuous Arc Design |
| Performance Advantage | 15-20% more turning power than conventional wrenches |
Order Snap-On 9/16" 12-Point SAE Flank Drive® Short Combination Wrench | OEX180B at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
