Professional 5/16-3/8" SAE Flank Drive® 12-point offset box wrench with short handle and 15° offset for accessing hard-to-reach fasteners. Premium alloy steel construction with precision forging and heat treatment.
The Snap-on 5/16-3/8" 12-Point SAE Flank Drive® Short High-Performance 15° Offset Box Wrench (Model XDHS1012) is a professional-grade hand tool engineered for demanding industrial applications. This premium wrench features a short handle design combined with a 15° offset box end, specifically engineered to access hard-to-reach fasteners in confined spaces. The innovative Flank Drive® box end wrenching system grips fasteners on their flanks and flats rather than corners, significantly increasing torque capacity while preventing corner rounding and fastener damage.
Manufactured from special alloy steel using precision forging and advanced heat-treatment processes, this wrench delivers optimum strength, durability, and reliability for professional mechanics and technicians. The 12-point design provides superior versatility, allowing engagement with fasteners from multiple angles. With an overall length of 7 inches and head dimensions carefully engineered for maximum accessibility, this tool is ideal for aviation, aerospace, automotive, and heavy-duty industrial maintenance applications. The high-performance construction ensures consistent performance across thousands of fastening operations.
This Snap-on wrench represents the pinnacle of hand tool engineering, combining ergonomic design with advanced metallurgy to deliver superior performance in the most challenging working environments. Whether you're working in confined engine compartments, tight machinery spaces, or complex assembly operations, this offset box wrench provides the precision grip and durability professionals demand.
Key Features
- Flank Drive® box end system grips fastener flanks and flats to increase torque and prevent corner rounding
- Short handle design combined with 15° offset provides superior access to hard-to-reach fasteners
- 12-point SAE design allows fastener engagement from multiple angles for enhanced versatility
- Premium special alloy steel construction with precision forging and heat treatment for maximum strength and durability
- Ideal for aviation, aerospace, automotive, and heavy-duty industrial maintenance applications
Technical Specifications
| Specification |
Value |
| Product SKU | XDHS1012 |
| Size Range | 5/16 - 3/8 inches |
| Point Configuration | 12-Point SAE |
| Offset Angle | 15 degrees |
| Handle Type | Short Handle |
| Overall Length | 7 inches |
| Outside Diameter (Dimension A) | 31/64 - 9/16 inches |
| Head Depth (Dimension C) | 1/4 - 5/16 inches |
| Material | Special Alloy Steel |
| Construction Method | Precision Forged and Heat-Treated |
| Wrench System | Flank Drive® Box End |
| List Price | $53.50 |
| Warranty | Snap-on Lifetime Warranty |
| Brand | Snap-on Incorporated |
| Application | Professional Hand Tool for Industrial Maintenance |
