Premium black VHB foam tape for residential window assembly with 48in x 36yd dimensions, 45 mil thickness, and permanent bonding strength ideal for muntin and grill bar attachment.
The 3M™ VHB™ Window Tape B45F is a premium black, multi-purpose acrylic foam adhesive tape specifically engineered for residential window assembly applications. Featuring a conformable foam core with a 45 mil (1.1 mm) thickness and polyethylene film liner, this tape provides fast and easy permanent bonding with exceptional strength and long-term durability. The tape measures 48 inches wide by 36 yards long, making it ideal for large-scale window projects including muntin bar attachment and grill bar assembly.
This innovative bonding solution combines the reliability of 3M's VHB technology with viscoelastic acrylic adhesive properties that create extraordinary bonding strength across a broad range of substrates including aluminum, painted aluminum, glass, plastics, and painted or sealed wood. The pressure-sensitive adhesive bonds on contact to provide immediate handling strength, eliminating the need for mechanical fasteners like screws and rivets. The virtually invisible fastening method keeps surfaces smooth while creating a permanent seal against water, moisture, and environmental elements.
Designed for industrial and occupational use, the 3M VHB Window Tape B45F offers excellent temperature resistance with a maximum operating temperature of 200°F (93°C), making it suitable for diverse climatic conditions. The tape is UL GREENGUARD and UL GREENGUARD Gold Certified, contributing to LEED credits for environmentally conscious construction projects. Each roll comes in a convenient single-roll case format, and the product is backed by 3M's commitment to quality, technical support, and design guidance.
Key Features
- Fast and easy permanent bonding method with high strength and long-term durability
- Virtually invisible fastening keeps surfaces smooth and aesthetically pleasing
- Conformable acrylic foam core with 45 mil thickness offers balanced strength and flexibility
- Creates permanent seal against water, moisture and environmental elements
- Pressure-sensitive adhesive provides immediate handling strength on contact
- Adheres to broad range of substrates including aluminum, glass, plastics and wood
- Maximum operating temperature of 200°F (93°C) for diverse climate conditions
- UL GREENGUARD and UL GREENGUARD Gold Certified for LEED credit contribution
- Eliminates need for mechanical fasteners like screws, rivets and welds
- Polyethylene film liner for optimal performance and easy application
Technical Specifications
| Specification |
Value |
| Part Number | B45F |
| 3M Product Number | B45F |
| 3M ID | 7010535843 |
| Overall Width (Imperial) | 48 inches |
| Overall Width (Metric) | 1,219.2 mm |
| Overall Length (Imperial) | 36 yards |
| Overall Length (Metric) | 32.91 meters |
| Total Tape Thickness without Liner (Imperial) | 45 mil |
| Total Tape Thickness without Liner (Metric) | 1.1 mm |
| Product Color | Black |
| Adhesive Type | Acrylic |
| Foam Type | Conformable |
| Liner Material | Polyethylene Film |
| Core Size (Imperial) | 3 inches |
| Maximum Operating Temperature (Fahrenheit) | 200°F |
| Maximum Operating Temperature (Celsius) | 93°C |
| Brand | VHB™ |
| Industry Application | Construction |
| Smallest Saleable Unit | Roll |
| Package Configuration | 1 Roll/Case |
| Certification | UL GREENGUARD and UL GREENGUARD Gold Certified |
| Adhesive Properties | Pressure-sensitive, viscoelastic acrylic with immediate handling strength |
| Substrate Compatibility | Aluminum, painted aluminum, glass, plastics, painted wood, sealed wood |
| Application Type | Residential window assembly, muntin bar attachment, grill bar attachment |
| Use Classification | Industrial/Occupational use only |
