Shop 3M VHB Tape Max-060GF Gray High-Performance Acrylic Foam In Iraq Best Prices
Premium high-performance acrylic foam tape with 470 psi bond strength, designed to replace mechanical fasteners and welding in demanding industrial applications. Includes 9 rolls per case, 1 inch x 36 yard dimensions, with immediate handling strength for faster assembly.
The 3M™ VHB™ Tape Max-060GF is a high-performance, double-sided acrylic foam tape engineered to replace traditional mechanical fasteners, welding, and liquid adhesives in demanding industrial applications. This premium bonding solution delivers exceptional bond strength of up to 470 psi (3.24 MPa) in overlap shear testing, significantly outperforming standard VHB tapes. The tape features a 0.6mm (25 mil) thickness with a polyethylene film liner and is available in a convenient 9 roll/case configuration, with each roll measuring 1 inch wide by 36 yards long.
Designed for versatility across multiple industries including transportation, building construction, appliances, and general manufacturing, the Max-060GF excels at bonding panels to frames, attaching stiffeners, and performing critical structural assembly tasks. The immediate handling strength enables faster assembly and processing times compared to traditional liquid adhesives, while the acrylic foam formulation provides excellent adhesion to a wide range of materials including metals and high surface energy substrates. The gray color and firm foam type ensure reliable performance in both indoor and outdoor environments.
This premium tape is part of the renowned 3M VHB Tape portfolio and is recommended for use with 3M VHB Tape Max Promoter to achieve optimal bond strength across various substrates and environmental conditions. With a 24-month shelf life and 3-inch core size, the Max-060GF represents the pinnacle of acrylic foam tape technology, offering greater design flexibility and reduced material usage through narrower bond lines compared to conventional alternatives.
Key Features
- Superior bond strength up to 470 psi (3.24 MPa) in overlap shear - significantly higher than standard VHB tapes
- Double-sided acrylic foam construction replaces mechanical fasteners, welding, and liquid adhesives
- Immediate handling strength enables faster assembly and processing compared to liquid adhesives
- Excellent adhesion to wide range of materials including metals and high surface energy substrates
- Available in multiple thicknesses (0.6mm, 1.1mm, 1.6mm, 2.3mm) for diverse industrial applications
- Firm foam type provides consistent performance in both indoor and outdoor environments
- Polyethylene film liner protects adhesive during storage and handling
- Greater design flexibility with narrower bond lines reducing total material usage
- Recommended for use with 3M VHB Tape Max Promoter for optimal substrate performance
- 24-month shelf life ensures extended product availability and reliability
Technical Specifications
| Specification |
Value |
| Product Number | Max-060GF |
| 3M ID | 7100364638 |
| UPC | 00068060759771 |
| Overall Width (Imperial) | 1 in |
| Overall Width (Metric) | 25.4 mm |
| Overall Length (Imperial) | 36 yd |
| Overall Length (Metric) | 32.9 m |
| Total Tape Thickness without Liner (Imperial) | 23.6 mil |
| Total Tape Thickness without Liner (Metric) | 0.6 mm |
| Liner Material | Polyethylene Film |
| Product Color | Gray |
| Foam Type | Firm |
| Adhesive Type | Acrylic |
| Core Size (Imperial) | 3 in |
| Core Size (Metric) | 76.2 mm |
| Shelf Life | 24 Month |
| Indoor/Outdoor | Indoor/Outdoor |
| Bond Strength (Overlap Shear) | 470 psi (3.24 MPa) |
| Smallest Saleable Unit | Roll |
| Case Configuration | 9 Roll/Case |
| Brand | 3M VHB™ |
Order 3M VHB Tape Max-060GF Gray High-Performance Acrylic Foam at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
