Premium gray acrylic foam adhesive tape for architectural panels, offering permanent bonding, invisible fastening, and exceptional durability. UL GREENGUARD certified with 30+ years of proven performance in iconic buildings worldwide.
The 3M™ VHB™ Architectural Panel Tape G16F is a premium gray, 0.062 inch (1.6 mm) multi-purpose acrylic foam adhesive tape designed specifically for architectural and construction applications. This innovative bonding solution features a conformable foam core with a polyethylene film liner, providing exceptional strength and long-term durability. The tape combines the benefits of permanent bonding with virtually invisible fastening, keeping surfaces smooth and aesthetically pleasing while delivering high-performance adhesion.
This architectural panel tape is engineered to replace traditional fastening methods such as structural silicone, spacer tapes, and gaskets in modern building construction. The viscoelastic acrylic adhesive formulation adheres reliably to a broad range of substrates including aluminum, stainless steel, galvanized steel, composites, plastics, acrylic, polycarbonate, ABS, and painted or sealed wood and concrete. With over 30 years of proven reliability in iconic buildings worldwide, the G16F tape provides excellent shear strength, conformability, surface adhesion, and superior temperature resistance ranging from -40°F to 300°F (-40°C to 149°C).
Each case contains 9 rolls of 36-yard length tape with a 1-inch width, making it ideal for large-scale architectural projects. The tape is UL GREENGUARD and UL GREENGUARD Gold Certified, contributing to LEED credits and supporting sustainable building practices. The pressure-sensitive adhesive bonds on contact to provide immediate handling strength, allowing architects and builders to use thinner, lighter weight, and dissimilar materials with confidence. This product is formulated for industrial and occupational use only.
Key Features
- Fast and easy-to-use permanent bonding method with high strength and long-term durability
- Virtually invisible fastening keeps surfaces smooth and aesthetically pleasing
- Conformable gray acrylic foam core with 0.062 inch (1.6 mm) thickness for optimal balance
- Creates permanent seal against water, moisture and environmental elements
- Pressure-sensitive adhesive provides immediate handling strength upon contact
- Adheres to broad range of substrates including metals, glass, plastics, composites and concrete
- Temperature resistant from -40°F to 300°F (-40°C to 149°C) for extreme climate applications
- UL GREENGUARD and UL GREENGUARD Gold Certified for sustainable building practices
- Prevents bi-metallic corrosion when joining dissimilar materials
- Polyethylene film liner provides easy application and handling
Technical Specifications
| Specification |
Value |
| Product Name | 3M VHB Architectural Panel Tape G16F |
| Part Number | G16F |
| 3M Product Number | G16F |
| 3M ID | 7100115581 |
| UPC Code | 00051111925348 |
| Product Color | Gray |
| Overall Width (Imperial) | 1 in |
| Overall Width (Metric) | 25.4 mm |
| Overall Length (Imperial) | 36 yd |
| Overall Length (Metric) | 32.92 m |
| Thickness | 0.062 in (1.6 mm) |
| Core Size (Imperial) | 3 in |
| Adhesive Type | Acrylic |
| Foam Type | Conformable |
| Liner Material | Polyethylene Film |
| Maximum Operating Temperature (Fahrenheit) | 300°F |
| Maximum Operating Temperature (Celsius) | 149°C |
| Minimum Operating Temperature (Fahrenheit) | -40°F |
| Minimum Operating Temperature (Celsius) | -40°C |
| Units per Case | 9 rolls |
| Smallest Saleable Unit | Roll |
| Brand | VHB™ |
| Industries | Construction, Transportation |
| Applications | Architectural Panel, Cladding Decorative Metal, Panels to Frame, Stiffener Attachment |
| Certifications | UL GREENGUARD, UL GREENGUARD Gold |
| Usage | Industrial/Occupational use only |
